Belden DataTwist CAT 6 Unshielded Twisted Pair Networking Cable

Belden® DataTwist® Cat 6 UTP Networking Cable – 1000′ Roll – Gray Jacket

DataTwist® 6 is a state of the art UTP cable engineered specifically to perform to Category 6 requirements per ANSI/TIA/EIA-568-B.2-1. DataTwist 6 is an unbonded-pair cable built to ensure performance. DataTwist 6 Cable is suitable for high bandwidth networks.

Features

• Guaranteed to meet or exceed TIA/EIA-568-B.2-1 Category 6
• Utilizes strict quality manufacturing processes to guarantee performance
• Sequential footage marking and a rip cord for easier installation.

Applications

• DataTwist 6 Cables are intended to be used for horizontal cable installations of high speed Local Area Networks (LANs). Specific applications include:
• All UTP Ethernet protocols (e.g. 1000Base-T, 100Base-TX, 100Base-T4, 100Base-T2 and 10 Base-T)
• All UTP ATM protocols
• 100 Mb/s TP-PMD.

Specifications

• Construction: Conductors: 23 AWG solid bare copper
• Insulation:
  – Non-Plenum: Polyolefin
  – Color coding as per ANSI/TIA/EIA-568-B.2-1.
• Cable Core:
  – Four twisted pairs, Rip Cord, rod filler
• Jacket:
  – Non-Plenum: PVC.

This Item is Sold in Spools of 1000 Feet.
