Cisco AIR-AP2802E-E-K9 WLAN access point Power over Ethernet (PoE) White 5200 Mbit/s

AIR-AP2802E-E-K9 is one of the Cisco Aironet 2800 Series Access Points. This 2800 series, delivering new 802.11ac Wave 2 standard, is ideal for large enterprise organizations that rely on Wi-Fi to engage with customers. The Series is a hands-off product thatā€™s intelligent enough to make decisions based on end-device activities and usage. AIR-AP2802E-E-K9 provides external antenna and E regulatory domain.



For organizations paving the way for the new 802.11ac Wave 2 standard, the Cisco Aironet 2800 Series is the perfect solution. The access points go beyond getting ready for the new standard, providing the ultimate in flexibility and versatility.

For large enterprise organizations that rely on Wi-Fi to engage with customers, the 2800 Series is a hands-off product thatā€™s intelligent enough to make decisions based on end-device activities and usage. This automation allows you to devote time to other pressing matters, secure in the knowledge that your Wi-Fi network is performing to its utmost potential.

The Aironet 2800 Series is packed with the features and capabilities that have made Cisco the industry leader, at a price point that is ideal for managing wireless growth, capacity, and coverage gaps in dense indoor environments.



Quick Specs

Table 1

Product Code AIR-AP2802E-E-K9
Frequency band and 20-MHz operating channels E (E regulatory domain):

– 2.412 to 2.472 GHz; 13 channels

– 5.180 to 5.320 GHz; 8 channels

– 5.500 to 5.700 GHz; 8 channels

(excludes 5.600 to 5.640 GHz)
Antenna External Antenna
Features – 4×4 MU-MIMO with three spatial streams

– MRC

– 802.11ac Beamforming

– 20-, 40-, 80, 160-MHz channels

– PHY data rates up to 5.2 Gbps

– Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

– 802.11 DFS

– CSD support
Interfaces – 2 x 100/1000BASE-T autosensing (RJ-45)

– Management console port (RJ-45)

– USB 2.0 (enabled via future software)
System memory – 1024 MB DRAM

– 256 MB flash
Dimensions (W x L x H) 8.66 x 8.77 x 2.50 in.
Net Weight 4.6 lb (2.09 kg)

Product Details

Figure 1 shows the face of AIR-AP2802E Model.

AIR-AP2802E Face



Figure 2 shows the Smart Antenna Connector and DART cable on the AIR-AP2802E model.

The 2802E model has a Smart antenna connector, which is connected directly to the flexible radio. Without a supported external antenna connected to the Smart Antenna connector, the flexible radio can stay only in 2.4 GHz mode. If an external antenna is connected, the flexible radio can be used in the full Flexible Radio Assignment mode, allowing dual 5 GHz and Wireless Security Monitoring modes.

To connect to any supported RP-TNC connector-type external antenna to the Smart antenna connector, use the DART cable connector AIR-CAB002-DART-R=, which is to be ordered separately.

Smart Antenna Connector and Cable

Table 2 shows the comparison between two AP.

Models AIR-AP2802E-E-K9 AIR-AP2802E-F-K9
Frequency band and

20-MHz operating channels

 E (E regulatory domain):

– 2.412 to 2.472 GHz; 13 channels

– 5.180 to 5.320 GHz; 8 channels

– 5.500 to 5.700 GHz; 8 channels

(excludes 5.600 to 5.640 GHz)

 F (F regulatory domain):

– 2.412 to 2.472 GHz; 13 channels

– 5.745 to 5.805 GHz; 4 channels
Antenna External Antenna External Antenna
Features – 4×4 MU-MIMO with three spatial streams

– MRC

– 802.11ac Beamforming

– 20-, 40-, 80, 160-MHz channels

– PHY data rates up to 5.2 Gbps

– Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

– 802.11 DFS

– CSD support

 – 4×4 MU-MIMO with three spatial streams

– MRC

– 802.11ac Beamforming

– 20-, 40-, 80, 160-MHz channels

– PHY data rates up to 5.2 Gbps

– Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

– 802.11 DFS

– CSD support
SKU: AIR-AP2802E-E-K9 Category: Tags: , , , ,

AIR-AP2802E-E-K9Ā Specification
Software
  • Cisco Unified Wireless Network Software Release 8.2.111.0 or later
  • Cisco IOSĀ®XE Software Release 16.3
Supported wireless LAN controllers
  • Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for CatalystĀ®6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco FlexĀ®Ā 7500 Series Wireless Controllers, Cisco 8500 Series Wireless Controllers, Cisco Virtual Wireless Controller
  • Cisco Catalyst 3850 Series Switches, Cisco Catalyst 3650 Series Switches
  • Cisco Mobility Express
802.11n version 2.0 (and related) capabilities
  • 4×4 MIMO with three spatial streams
  • Maximal ratio combining (MRC)
  • 802.11n and 802.11a/g beamforming
  • 20- and 40-MHz channels
  • PHY data rates up to 450 Mbps (40 MHz with 5 GHz)
  • Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
  • 802.11 dynamic frequency selection (DFS)
  • Cyclic shift diversity (CSD) support
802.11ac Wave 1 capabilities
  • 4×4 MIMO with three spatial streams
  • MRC
  • 802.11ac beamforming
  • 20-, 40-, and 80-MHz channels
  • PHY data rates up to 1.3 Gbps (80 MHz in 5 GHz)
  • Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
  • 802.11 DFS
  • CSD support
802.11ac Wave 2 capabilities
  • 4×4 MU-MIMO with three spatial streams
  • MRC
  • 802.11ac beamforming
  • 20-, 40-, 80, 160-MHz channels
  • PHY data rates up to 5.2 Gbps
  • Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
  • 802.11 DFS
  • CSD support
Integrated antenna Flexible radio (either 2.4 GHz or 5 GHz)

  • 2.4 GHz, gain 4 dBi, internal antenna, omnidirectional in azimuth
  • 5 GHz, gain 6 dBi, internal directional antenna, elevation plane beamwidth 90Ā°

Dedicated 5-GHz radio

  • 5 GHz, gain 5 dBi, internal antenna, omnidirectional in azimuth
External antenna (soldĀ separately)
  • 2802e Series access points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)
  • Cisco offers the industry’s broadest selection ofantennas, delivering optimal coverage for a variety of deployment scenarios
Smart antenna connector
  • Available on the 2802e Series access points only
  • Requires the AIR-CAB002-DART-R= 2 ft smart antenna connector to RP-TNC connectors to connect a second antenna to the access point
  • Required when running the flexible radio as either a second 5-GHz serving radio or Wireless Security Monitoring radio
Interfaces
  • 2802I/E
  • 2×100/1000BASE-T autosensing (RJ-45)
  • Management console port (RJ-45)
  • USB 2.0 (enabled via future software)
Indicators
  • Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors
Dimensions (WĀ xĀ LĀ xĀ H)
  • Access point (without mounting brackets): 2802I: 8.66ā€ x 8.68ā€ x 2.17ā€, 2802E: 8.66ā€ x 8.77ā€ x 2.50ā€
Weight Cisco Aironet 2802i

  • 3.53 lb (1.6 kg)

Cisco Aironet 2802e

  • 4.6 lb (2.09 kg)
Input power requirements
  • 802.3at PoE+, Cisco Universal PoE (Cisco UPOEĀ®)
  • 802.3at power injector (AIR-PWRINJ6=)
Power draw
  • 26W at the PSE with all features enabled except for the USB 2.0 port
  • 30W at the PSE with the USB 2.0 port enabled
Environmental Cisco Aironet 2802i

  • Nonoperating (storage) temperature: -22Ā° to 158Ā°F (-30Ā° to 70Ā°C)
  • Nonoperating (storage) altitude test: 25ĖšC, 15,000 ft.
  • Operating temperature: 32Ā° to 104Ā°F (0Ā° to 40Ā°C)
  • Operating humidity: 10% to 90% (noncondensing)
  • Operating altitude test: 40ĖšC, 9843 ft.

Cisco Aironet 2802e

  • Nonoperating (storage) temperature: -22Ā° to 158Ā°F (-30Ā° to 70Ā°C)
  • Nonoperating (storage) altitude test: 25ĖšC, 15,000 ft.
  • Operating temperature: -4Ā° to 122Ā°F (-20Ā° to 50Ā°C)
  • Operating humidity: 10% to 90% (noncondensing)
  • Operating altitude test: 40ĖšC, 9843 ft.
System memory
  • 1024 MB DRAM
  • 256 MB flash
Warranty Limited lifetime hardware warranty
