4-Port DisplayPort KVM Switch, 8K 60Hz / 4K 144Hz, Single Display, DP 1.4, 2x USB 3.0 Ports, 4x USB 2.0 HID Ports, Push-Button & Hotkey Switching, TAA Compliant – OS Independent, Metal Housing


  • 8K 60HZ WITH HDR: Fast switch between four USB-A and DisplayPort-enabled desktops to share a keyboard, mouse, audio device, and a single 8K 60Hz DisplayPort monitor; DSC support required for maximum video performance; Supports MST Pass-through
  • UNIVERSAL COMPATIBILITY: TAA-Compliant KVM Switch works with any operating system including Windows, macOS, ChromeOS, and Linux; Compatible with all hardware platforms such as Intel and AMD; Supports ultrawide resolutions up to 5120×1440 60Hz
  • MULTIPLE SWITCHING OPTIONS: Fast Switching via push-buttons or hotkeys with an audible buzzer providing confirmation; LEDs provide quick visual port selection status; Listen to audio from one computer while controlling another
  • THOUGHTFUL DESIGN: Metal housing is durable and helps prevent Electro-magnetic Interference (EMI); Overcurrent Protection (OCP) prevents peripherals from overdrawing power, reducing the risk of damage to the KVM and attached USB devices
  • TECHNICAL SPECIFICATIONS: KVM Switch is DisplayPort 1.4 compliant, supporting resolutions up to 8K 60Hz or 4K 144Hz, HDR10, HDCP 2.2/1.4, and DSC; Supports DisplayPort Audio and 3.5mm analog audio; USB 5Gbps Hub Ports; OS Independent

AED2,999.00

Share and switch between four USB-A and DisplayPort-enabled computers, using this DisplayPort KVM Switch. Share an 8K 60Hz DisplayPort monitor, a keyboard and mouse, two USB 5Gbps devices, and two additional USB 2.0 devices.

High-Resolution 8K 60Hz Video

This KVM supports resolutions up to 8K 60Hz or 4K 144Hz/120Hz. Daisy chain additional monitors via MST pass-through. The KVM supports ultrawide resolutions of up to 5120×1440 at 60Hz. Ideal for applications such as CAD/CAM, video editing, and content creation. Support for High Dynamic Range (HDR) offers increased contrast, brightness, colors, and greater luminosity.

Customizable Switching

This Universal KVM Switch provides various switching options, including hotkey or push-button switching. Hotkeys allow for independent switching of audio and video, enabling audio playback from one computer while controlling another. An audible buzzer confirms hotkey input, and LEDs provide a visual status of the selected host.

Universal Compatibility

The TAA-Compliant KVM Switch offers universal compatibility, working with all operating systems, including Windows, macOS, ChromeOS, and Linux. It is also compatible with all hardware platforms, including Intel and AMD.

Reliable Performance

The durable metal housing helps prevent electromagnetic interference (EMI). Overcurrent Protection (OCP) ensures peripherals don’t overdraw power, reducing the occurrence of device dropouts or shutdowns.

Rackmount your KVM switch

If you’d like to mount this KVM switch to your server rack, we offer aĀ 1U Rackmount BracketĀ (sold separately) that turns this KVM into a rackmountable KVM.


Applications

  • Share a monitor, mouse, keyboard, and audio peripheral between four desktop computers
  • Great for applications like CAD/CAM, video editing, and content creation
SKU: D86A2-4-PORT-8K-KVM Category: Tag:

🧾Product Specifications


šŸ”Œ Connectors Overview

Console Interface Ports

Type Details
USB 3.2 Type-A 2 Ɨ 9-pin (5Gbps)
USB 2.0 Type-A 4 Ɨ 4-pin (480Mbps)
DisplayPort 1 Ɨ DisplayPort
Audio Out 1 Ɨ 3.5mm Stereo Female (3-pos)
Power Connector 1 Ɨ Barrel (Size M, OD:5.50, ID:2.10mm)

Host Connectors

Type Details
USB 3.2 Type-B 4 Ɨ 9-pin Gen 1 (5Gbps)
DisplayPort 4 Ɨ DisplayPort
Audio 4 Ɨ 3.5mm Stereo Female (3-pos)

šŸŒ”ļø Environmental Specifications

Condition Range
Operating Temp 0°C to 40°C (32°F to 104°F)
Storage Temp -20°C to 60°C (-4°F to 140°F)
Humidity 0% ~ 85% RH (Non-condensing)

āš™ļø Hardware Details

Attribute Specification
Audio Support Yes
KVM Ports 4
PC Interface USB 3.2 Gen 1 (5Gbps)
PC Video Type DisplayPort
Number of Monitors 1
Rack-Mountable No
Cables Included No
Chipset ID GL-3523
Daisy-Chain Support No

šŸ’” LED Indicators

Indicator Type Meaning
4 Ɨ Green LED PC Connected (Power ON)
1 Ɨ Red LED PC Selected (Power ON)

šŸ“¦ Packaging Information

Attribute Value
Package Height 3.4 in [8.7 cm]
Package Length 9.6 in [24.5 cm]
Package Width 11.7 in [29.7 cm]
Shipping Weight 3.5 lb [1.6 kg]
Package Quantity 1

šŸš€ Performance

Feature Specification
On-Screen Display (OSD) No
DisplayPort Revision 1.4
IP Control No
Hot-Key Selection Yes
Max Data Transfer Rate 5Gbps
Max Digital Resolution 7680 Ɨ 4320 @ 60Hz
Wide Screen Support Yes
Auto Scan Intervals 3, 8, 15, & 30 seconds
Port Selection Push Button & Hotkeys
MTBF (Mean Time Between Failures) 130,000 Hours

šŸ”Š Audio Specifications

Type Channel Support
DisplayPort Audio 2-Channel
Analog Stereo Audio 2-Channel

🧱 Physical Characteristics

Attribute Measurement
Color Black
Product Height 1.7 in [4.4 cm]
Product Length 8.7 in [22.0 cm]
Product Width 5.1 in [13.0 cm]
Product Weight 2.3 lb [1.0 kg]
Material Steel

šŸ”Œ Power Specifications

Attribute Details
Power Source AC Adapter (Included)
Input Voltage 100 – 240V AC
Input Current 1.0A
Output Voltage 12V DC
Output Current 3A
Center Tip Polarity Positive
Plug Type M
Power Consumption 36W

šŸ’» Software Compatibility

Requirement Detail
Driver/Software Needed No Drivers or Software Required

ā— Special Notes / System Requirements

  • Requires host with DisplayPort 1.4 and DSC support for optimal performance.


šŸ“¦ In the Box

Item
1 Ɨ KVM Switch
1 Ɨ Quick-Start Guide
1 Ɨ Universal Power Adapter (NA/JP, EU, UK, NZ)
4 Ɨ Rubber Feet
