4 Port HDMI KVM Switch – 4K 30Hz – Dual Display – TAA

Add to Wishlist

This 4K HDMI KVM with dual monitor support lets you control four HDMI computers with a single mouse, keyboard and dual monitors up to 4K at 30Hz



  • High-definition video quality with support for dual 4K at 30Hz displays
  • Two built-in USB 3.0 ports and independent HID keyboard/mouse ports
  • No software or drivers required
  • Separate the 3.5 mm auxiliary support
  • Supports push-button and hotkey switching

AED3,799.00

Add to Wishlist
This 4-port HDMI KVM switch lets you control four HDMI computers with a single mouse, keyboard and monitor up to 4K 30Hz. The KVM also features 3.5 mm audio and a built-in 2-port USB 3.0 hub.

4K at 30Hz UHD dual display

With support for ultra-high-definition 4K 30Hz resolutions,Ā this 4-port KVM switch can drive dual HDMIĀ displaysĀ with crystal clarity, making it ideal for graphical applications that require UHD capability.

Convenient and cost-effective USB 3.0 peripheral sharing

This 4-port KVM switch offers two USB 3.0 ports, as well as four HID keyboard and mouse ports, so you can share peripheral devices between each computer and avoid the cost of separate equipment.Ā The USB 3.0Ā hub automatically switches your connected devices to the selected computer, saving you the hassle ofĀ disconnectingĀ and reconnecting peripherals.

Complete multimedia capability

Along with dual UHD video capability, this KVM switch features auxiliary 3.5 mm dual-channel bi-directional audio ports. This independent analog audio lets you share your analog audio devices such as speakers or a microphone between each of your connected computers, giving you complete multimedia control of your systems.



Applications

  • Ideal for applications that require two displays at high resolutions such as graphic design, medical imaging, digital signage, and multimedia design across four computers
  • Great for those who need to share high-speed storage between up to four systems
  • Perfect for creative professional applications such as video and sound design or editing
Category: Tag:

āœ… Specifications

šŸ”Œ Connector(s)

Type Description
Console Interface(s) – 2 Ɨ HDMI
– 4 Ɨ USB Type-A (USB 1.1 HID)
– 2 Ɨ USB 3.2 Type-A (Gen 1, 5Gbps)
– 1 Ɨ 3.5mm Stereo Female (3-pos)
Host Connectors – 8 Ɨ HDMI
– 4 Ɨ USB 3.2 Type-B (Gen 1, 5Gbps)
– 4 Ɨ 3.5mm Stereo Female (3-pos)

šŸŒ”ļø Environmental

Feature Value
Operating Temperature 0Ā°C ~ 40Ā°C
Storage Temperature -10Ā°C ~ 60Ā°C
Humidity 0% ~ 80%

āš™ļø Hardware

Feature Value
Audio Yes
KVM Ports 4
PC Interface USB
PC Video Type HDMI
Number of Monitors 2
Rack-Mountable Optional
Cables Included No
Daisy-Chain No

šŸ’” Indicators

LED Indicators
– 4 Ɨ LED (Source Status and Selected PC)
– 1 Ɨ Power LED

šŸ“¦ Packaging Information

Feature Value
Package Quantity 1
Shipping Weight 3.9 lb [1.8 kg]
Package Length 9.9 in [25.2 cm]
Package Width 11.7 in [29.6 cm]
Package Height 3.5 in [8.8 cm]

šŸš€ Performance

Feature Value
IP Control No
Hot-Key Selection Yes
Max Data Transfer Rate 5 Gbps
Max Digital Resolution 3840 Ɨ 2160 @ 30Hz
Wide Screen Supported Yes
Auto Scan 3, 8, 15 & 30 seconds
Port Selection Push Button and Hotkeys
3D Video Support Yes
MTBF 168,000 hours

šŸ§± Physical Characteristics

Feature Value
Color Black
Material Steel
Product Length 8.7 in [22.0 cm]
Product Width 5.1 in [13.0 cm]
Product Height 2.5 in [6.3 cm]
Weight 2.7 lb [1.2 kg]

šŸ”‹ Power

Feature Value
Power Source AC Adapter Included
Input Voltage 100 – 240 AC
Input Current 0.6 A
Output Voltage 12V DC
Output Current 1.5 A
Center Tip Polarity Positive
Plug Type M
Power Consumption 18W

šŸ“¦ What’s in the Box

Included Items
1 Ɨ KVM Switch
1 Ɨ Quick-Start Guide
4 Ɨ Rubber Feet
1 Ɨ Universal Power Adapter (NA/JP, UK, EU, ANZ)
