KVM Switches
8 Port 1U Rackmount DVI USB KVM Switch – TAA
Control up to 8 USB computers with DVI or HDMIĀ® video, from one keyboard, mouse and monitor
- Supports DVI/HDMI resolutions up to 1920×1200
- Can be used with DVI to HDMI adapters to connect HDMI based systems
- Support for most combo/wireless keyboards and mice
- OS independent ā No software or drivers required
- Front panel push-buttons and Hot-key functions allow for easy switching
- Auto-scan function cycles through computers sequentially
- Connects to USB-based computer systems
- USB console interfaces for keyboard and mouse
- Supports MacĀ® and Sun keyboard mapping – Keyboard states are automatically saved and restored when switching computers
- Supports Microsoft IntelliMouse (Pro)
AED4,699.00
The KVM switch offers maximum control, allowing you to switch computers using hot-key commands or front panel buttons. Supporting digital resolutions up to 1920×1200 via DVI or HDMI connection (using DVI to HDMI adapter – see accessories), the KVM provides the high resolutions recommended for newer displays, allowing you to take full advantage of your monitor/screen capability.
A perfect addition to any server room or software test lab, this 8-port switch can be rack-mounted into 1U of cabinet space.
Note: This KVM supports digital signals only, and cannot be used with DVI-to-VGA adapters.Ā
Applications
- Ideal for software development and QA test labs with multiple PCs and platforms connected to one console
- Single console administration of your co-location/ISP facility
- Create a streamlined access solution in your Datacenter or Server Farm
- Great for PC test/burn-in computer control saving the desk space required for multiple monitors, keyboards and mice
- Perfect for manufacturing line computer control, simplifying access to multiple systems
ā 8-Port DVI USB KVM Switch ā Product Specifications
š Compatibility
| Feature | Description |
|---|---|
| Compatibility | OS Independent ā No software or drivers required |
š Connector(s)
| Connector Type | Quantity & Description |
|---|---|
| Console Interface(s) | 1 Ć DVI-I (29 pin) |
| 2 Ć USB 2.0 Type-A (4 pin, 480Mbps) | |
| Host Connectors | 8 Ć DVI-I (29 pin) |
| 8 Ć USB B (4 pin) |
š”ļø Environmental
| Feature | Range |
|---|---|
| Operating Temp. | 0Ā°C to 40Ā°C (32Ā°F to 104Ā°F) |
| Storage Temp. | -20Ā°C to 60Ā°C (-4Ā°F to 140Ā°F) |
| Humidity | 0~80% RH |
āļø Hardware
| Feature | Description |
|---|---|
| Audio Support | No |
| KVM Ports | 8 |
| PC Interface | USB |
| PC Video Type | DVI |
| Monitors Supported | 1 |
| Rack-Mountable | Yes |
| Daisy-Chain | No |
| Cables Included | No |
| U Height | 1U |
š¦ Packaging
| Feature | Measurement |
|---|---|
| Package Quantity | 1 |
| Package Length | 10.4 in [26.5 cm] |
| Package Width | 23.4 in [59.5 cm] |
| Package Height | 3.5 in [9.0 cm] |
| Shipping Weight | 8.2 lb [3.7 kg] |
š Performance
| Feature | Description |
|---|---|
| On-Screen Display (OSD) | No |
| DVI Support | Yes ā Single Link |
| IP Control | No |
| Hot-Key Selection | Yes |
| Max Cable Length | 15.0 ft [4.6 m] |
| Max Digital Resolution | 1920 Ć 1200 |
| Port Selection Support | Push Button and Hotkeys |
| Maximum Users Supported | 1 |
| MTBF | 134,000 hours |
š§± Physical Characteristics
| Feature | Description |
|---|---|
| Color | Black |
| Material | Steel |
| Product Width | 17.2 in [43.8 cm] |
| Product Height | 1.7 in [4.4 cm] |
| Product Depth | 7.1 in [18 cm] |
| Product Weight | 5.5 lb [2.5 kg] |
š Power
| Feature | Description |
|---|---|
| Power Source | AC Adapter Included |
| Input Voltage | 100 – 240 AC |
| Input Current | 1.8A |
| Output Voltage | 12V DC |
| Output Current | 4A |
| Center Tip Polarity | Positive |
| Plug Type | M |
| Power Consumption | 48 Watts |
š„ļø Software
| Feature | Description |
|---|---|
| OS Compatibility | OS Independent ā No software or drivers required |
ā Special Notes
-
Supports SUN keyboard emulation
š¦ Included in the Box
| Item | Quantity |
|---|---|
| 8-Port DVI USB KVM Switch | 1 |
| Rack-Mount Brackets | 1 Set |
| Universal Power Adapter (region-specific) | 3 |
| User Manual | 1 |
