A-Neuvideo 16×1 HDMI Quad Screen Multiviewer and Seamless Switcher

Add to Wishlist
  • Streams 16 HDMI Inputs to 1 HDMI Output
  • Multiview or Switch between Inputs
  • Supports up to 1080p Resolution
  • Front-Panel Buttons and RS-232 Control
  • Scale-Up and Scale-Down Functions
  • HDMI 1.3 and HDCP 1.2 Compliant
  • Audio Output Formats up to 7.1 Surround
  • 2.25 Gb/s Bandwidth
  • Included RS-232 Cable and Power Adapter

د.إ11,799.00

Add to Wishlist

Show up to 16 HDMI sources on one screen to enhance your next presentation, conference, or lecture with the A-Neuvideo 16×1 HDMI Quad Screen Multiviewer and Seamless Switcher. Four picture modes allow you to optimize the viewing experience for your audience in many educational presentation applications from exhibition halls or classrooms. Using the front panel or RS-232 controls through the included cable, you can easily set up the resolution, mode, and input selection.

The switcher supports up to 1080p HD resolution and features both scale-up and scale-down functions for proper, high-quality image display. On the audio side, it supports stereo and multichannel audio formats up to 7.1 surround sound. For versatile placement, the switcher can be set on a table or secured in a rack with the included mounting ears.

Key Features
Maximum bandwidth of 2.25 Gb/s
HDMI 1.3 and HDCP 1.2 compliant
Supports PCM2, 5.1, 7.1Ch, Dolby 5.1, and DTS5.1 audio outputs

UPC: 859777007428
SKU: ANI-16-MV Category: Tag:
Processing
Switching Type
Pushbutton
Input
Video Inputs
16x HDMI Female
1x DB-25
Input Video Format
HDMI
480i / 525 lines at 60 fps
480p at 60 fps
576i / 625 lines at 50 fps
576p at 50 fps
720p at 50/60 fps
1080i at 50/60 fps
1080p at 24/30/50/60 fps
SVGA (800 x 600) at 60 fps
1280 x 768 at 60 fps
Output
Video Outputs
1x HDMI Female
Output Video Format
HDMI
1080p
1080i
720p
1280 x 768
Audio Outputs
1x TOSLINK
Output Audio Format
LPCM (Linear Pulse-Code Modulation)
Connectivity
HDCP Support
Yes, Version 1.2
DTS Compatibility
DTS
Hardware
Wi-Fi
No
Bluetooth
No
Power
Power I/O
1x Barrel (12 VDC at 5 A) Input/Output
Power Consumption
Device: 24 W
Environmental
Operating Temperature
32 to 72°F / 0 to 40°C
Storage Temperature
-4 to 140°F / -20 to 60°C
Operating Humidity
20 to 90%
General
Rack Form Factor
1 RU
Dimensions
17.3 x 7.9 x 1.8″ / 43.9 x 20.1 x 4.6 cm
Weight
4 lb / 1.8 kg
