AIR-AP3802I-H-K9C – Cisco Aironet 3802i Access Point


802.11ac Wave 2 AP w/CleanAir, 4×4:3, Mod, Internal Antenna, mGig, H Regulatory Domain, Configurabl

133,099.00 د.إ

AIR-AP3802I-H-K9C Overview

AIR-AP3802I-H-K9C is one of the Cisco 3800 Series Access Points. The Cisco Aironet 3800 Wi-Fi access points are designed for large enterprise organizations that rely on Wi-Fi to engage with customers. The 3800 series provides multiple gigabit uplink speeds of 2.5 Gbps and 5 Gbps in addition to 100-Mbps and 1-Gbps speeds. It also delivers new 802.11ac Wave 2 standard. Cisco Aironet 3800 Series Wi-Fi access points are highly versatile and deliver the most functionality of any access points in the industry. AIR-AP3802I-H-K9C is designed for Indoor, challenging environments, with internal antennas. Besides, it provides H regulatory domain and Dual-band, controller-based 802.11a/g/n/ac, configurable.

Quick Specs

Table 1 shows the quick specs of AIR-AP3802I-H-K9C.

Product Code AIR-AP3802I-H-K9C
Antennas Internal Antennas
Description Dual-band, controller-based 802.11a/g/n/ac, configurable
Interfaces – 2 Ethernet ports

– 100/1000/2500/5000 Multigigabit Ethernet (RJ-45)

– CAT 5e cabling

– Higher-quality 10GBASE-T (CAT 6/6a) cabling

– 100/1000BASE-T autosensing (RJ-45 – AUX port)

– Management console port (RJ-45)

Features – 4×4 MU-MIMO with three spatial streams

– MRC

– 802.11ac beamforming

– 20-, 40-, 80, 160-MHz channels

– PHY data rates up to 5.2 Gbps

– Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

– 802.11 DFS

– CSD support

Regulatory Domain H (H regulatory domain):

– 2.412 to 2.472 GHz; 13 channels

– 5.150 to 5.320 GHz; 8 channels

– 5.745 to 5.825 GHz; 5 channels

System – 1024 MB DRAM

– 256 MB flash

Dimensions (W x L x H) 8.66 x 8.68 x 2.46 in. (22 x 22 x 6.25 cm)
Net Weight 4.6 lb (2.09 kg)

Product Details

Figure 1 shows the face of the AIR-AP3802I.

AIR-AP3802I Appearance

Note:

ā‘  Status LED
ā‘” Location of the ports and connectors on the head of the AP
ā‘¢ Location of the module connector port on the base of the AP

Module Connector Port:Ā The AP 3800 has modularity support. This module design allows for installation onto the side of the access point. This allows for larger antenna arrays and does not constrict the development of Cisco and potentially third party modules as they are no longer limited by the physical size of the access point. Additionally, filtering is installed on the AP 3800 for cellular and other radio coexistence.

Figure 2 shows ports and connections on the head of the AP.

AIR-AP3802I Ports

Note:

ā‘  Kensington lock slot ⑤ AUX / Gigabit Ethernet port
ā‘” Mode button ā‘„ PoE / mGig port
ā‘¢ Console port ⑦ 48 VDC power port
ā‘£ USB port



SKU: AIR-AP3802I-H-K9C Category: Tag:

AIR-AP3802I-H-K9C Overview

AIR-AP3802I-H-K9C is one of the Cisco 3800 Series Access Points. The Cisco Aironet 3800 Wi-Fi access points are designed for large enterprise organizations that rely on Wi-Fi to engage with customers. The 3800 series provides multiple gigabit uplink speeds of 2.5 Gbps and 5 Gbps in addition to 100-Mbps and 1-Gbps speeds. It also delivers new 802.11ac Wave 2 standard. Cisco Aironet 3800 Series Wi-Fi access points are highly versatile and deliver the most functionality of any access points in the industry. AIR-AP3802I-H-K9C is designed for Indoor, challenging environments, with internal antennas. Besides, it provides H regulatory domain and Dual-band, controller-based 802.11a/g/n/ac, configurable.

Quick Specs

Table 1 shows the quick specs of AIR-AP3802I-H-K9C.

Product Code AIR-AP3802I-H-K9C
Antennas Internal Antennas
Description Dual-band, controller-based 802.11a/g/n/ac, configurable
Interfaces – 2 Ethernet ports

– 100/1000/2500/5000 Multigigabit Ethernet (RJ-45)

– CAT 5e cabling

– Higher-quality 10GBASE-T (CAT 6/6a) cabling

– 100/1000BASE-T autosensing (RJ-45 – AUX port)

– Management console port (RJ-45)

Features – 4×4 MU-MIMO with three spatial streams

– MRC

– 802.11ac beamforming

– 20-, 40-, 80, 160-MHz channels

– PHY data rates up to 5.2 Gbps

– Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

– 802.11 DFS

– CSD support

Regulatory Domain H (H regulatory domain):

– 2.412 to 2.472 GHz; 13 channels

– 5.150 to 5.320 GHz; 8 channels

– 5.745 to 5.825 GHz; 5 channels

System – 1024 MB DRAM

– 256 MB flash

Dimensions (W x L x H) 8.66 x 8.68 x 2.46 in. (22 x 22 x 6.25 cm)
Net Weight 4.6 lb (2.09 kg)

Product Details

Figure 1 shows the face of the AIR-AP3802I.

AIR-AP3802I Appearance

Note:

ā‘  Status LED
ā‘” Location of the ports and connectors on the head of the AP
ā‘¢ Location of the module connector port on the base of the AP

Module Connector Port:Ā The AP 3800 has modularity support. This module design allows for installation onto the side of the access point. This allows for larger antenna arrays and does not constrict the development of Cisco and potentially third party modules as they are no longer limited by the physical size of the access point. Additionally, filtering is installed on the AP 3800 for cellular and other radio coexistence.

Figure 2 shows ports and connections on the head of the AP.

AIR-AP3802I Ports

Note:

ā‘  Kensington lock slot ⑤ AUX / Gigabit Ethernet port
ā‘” Mode button ā‘„ PoE / mGig port
ā‘¢ Console port ⑦ 48 VDC power port
ā‘£ USB port
