AJA HDP3 3G-SDI to DVI-D and Audio Converter

Add to Wishlist
Key Features
  • Convert 3G-SDI to DVI-D and Analog Audio
  • Output Video to Monitor, Projector, DLP
  • Up to 1080p & 1920 x 1200 Resolution
  • 24-Bit and 30-Bit Deep Color Support
  • Auto-Scaling to/from 4:3 and 16:9
  • 2-Channel RCA Audio Output
  • HD-SDI Loop Output

AED4,399.00

Add to Wishlist

The HDP3 3G-SDI to DVI-D and Audio Converter from AJA is a compact converter with support for 3G-SDI input up to 1080p60 and 1920 x 1200, and a DVI-D output for devices such as LCD, DLP, and plasma monitors or projectors. The converter scales, deinterlaces, and automatically resizes 4:3 or 16:9 video input and outputs to a DVI-D display. The converter can input and output up to eight channels of embedded audio over DVI-D and the 3G-SDI loop output as well as split the audio output to the stereo 2RCA analog output.

General
  • HD-SDI/SDI to DVI-D
  • HDMI 1.3a support via DVI-D connector, including deep color 30-bit video (24-bit also supported), 2 or 8 channels of embedded audio
  • Automatically adapts to popular LCD / DLP / Plasma monitors and projectors up to 1920 x 1200 and 1080p
  • High-quality scaling engine for proper display of 4:3 or 16:9 content
  • 1 to 1 scaling for appropriate monitor configurations
  • 2-channel RCA analog audio output (user-assignable channels)
  • HD-SDI/SDI looping output
  • Setup via Windows/Mac using USB port and supplied USB cable (USB configuration software application supplied on CD)
Compact and Portable
The HDP3 is small enough to fit behind a monitor, in the back of a rack, or directly on a camera rig
Universal Power Supply
Ships with a universal power supply unit that includes international plug connections for use around the world, and it plugs into the unit’s locking power connector
SKU: HDP3 Category: Tag:
Inputs / Outputs
Video Inputs
1x BNC (3G-SDI) Female
Audio Inputs
No
Video Outputs
1x DVI-D DL (DVI/HDMI 1.3) Female
1x BNC (HD-SDI) Female (Loop Output)
Audio Outputs
1x 2RCA Stereo Analog Female
Expansion Slots
No
Format Support
Input Video Format
SDI
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
1080i at 50/59.94/60 fps
1080i at 50/59.94/60 fps
576i / 625 lines at 50 fps
480i / 525 lines at 60 fps
Output Video Format
DVI
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
WUXGA (1920 x 1200) at 60 fps
576i / 625 lines at 50 fps
480i / 525 lines at 60 fps
Output Audio Format
Analog: 24-Bit
Embedded Audio
SDI: 8-Channel
HDMI: 2-Channel
Standards
Video Standard Compliance
SMPTE 259M/292M/424M-A/424M-B
EDID Support
Auto-Detect
HDR Support
Not Specified by Manufacturer
Wireless
Yes
Power
Power I/O
1x Proprietary (5 to 20 VDC ) Input
Power Consumption
Device: 6.5 W
Environmental
Operating Temperature
32 to 104°F / 0 to 40°C
Storage Temperature
-40 to 140°F / -40 to 60°C
Operating Humidity
10 to 90%
General
Rack Form Factor
No
Dimensions
5.8 x 3.1 x 1″ / 14.73 x 7.87 x 2.54 cm
Weight
11.22 oz / 318 g
Packaging Info
Package Weight
1.62 lb
Box Dimensions (LxWxH)
7.1 x 6 x 4.2″
