General |
|
Device Type |
Network adapter |
Form Factor |
Plug-in card |
Interface (Bus) Type |
PCI Express x4 |
PCI Specification Revision |
PCIe 3.0 |
Bus Voltage |
3.3 V |
Networking |
|
Ports |
1/2.5/5/10GBase-T x 1 |
Connectivity Technology |
Wired |
Cabling Type |
Ethernet 10GBase-T |
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet, 5 Gigabit Ethernet, 2.5 Gigabit Ethernet |
Data Transfer Rate |
10 Gbps |
Remote Management Protocol |
SNMP |
Status Indicators |
Link/activity |
Features |
Flow control, VLAN support, wake on LAN (WOL), IPv6 support, Quality of Service (QoS), Link Aggregation Control Protocol (LACP), PXE 2.1 support, Priority-Based Flow Control (PFC), failover protection, VLAN filtering, UEFI Secure Boot, VLAN Tagging, Enhanced transmission selection (ETS), Quantized Congestion Notification (QCN), Jumbo Frames support (up to 16348 bytes), ACPI 1.1 support |
Compliant Standards |
IEEE 802.2, IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 801.1Qau |
Expansion / Connectivity |
|
Interfaces |
1 x 10GBase-T – RJ-45 |
Miscellaneous |
|
Included Accessories |
Low-profile bracket |
Compliant Standards |
VCCI, FCC, RoHS, EN 55032 Class B, IEC 62368-1, UL 62368-1, EN 55035 |
TAA Compliant |
Yes |
Power |
|
Power Consumption Operational |
6 Watt |
Software / System Requirements |
|
OS Required |
Windows 10, Microsoft Windows Server 2019 |
Dimensions & Weight |
|
Width |
3.5 in |
Depth |
2.7 in |
Height |
0.5 in |
Weight |
2.75 oz |
Environmental Parameters |
|
Min Operating Temperature |
32 °F |
Max Operating Temperature |
104 °F |
Humidity Range Operating |
5 – 90% (non-condensing) |
