| Switch Type |
Managed |
| Switch Layer |
L3 |
| Quality of Service (QoS) Support |
Yes |
| Web-based Management |
Yes |
| Traffic Classification |
Yes |
| ARP Inspection |
Yes |
| System Event Log |
Yes |
| MIB Support |
SNMP MIB |
| Basic Switching RJ-45 Ethernet Ports Quantity |
8 |
| Basic Switching RJ-45 Ethernet Ports Type |
Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (Copper) Ports Quantity |
8 |
| Combo SFP Ports Quantity |
2 |
| Fiber Optic Connector |
SFP |
| Console Port |
RS-232 |
| Compatible Memory Cards |
SD, SDHC |
| Networking Standards |
IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G Support |
No |
| Copper Ethernet Cabling Technology |
10BASE-T, 100BASE-T, 1000BASE-T |
| Port Mirroring |
Yes |
| Full Duplex |
Yes |
| Flow Control Support |
Yes |
| Link Aggregation |
Yes |
| Broadcast Storm Control |
Yes |
| Spanning Tree Protocol |
Yes |
| Ethernet Ring Protection Switching (ERPS) |
Yes |
| Fast Leave |
Yes |
| VLAN Support |
Yes |
| Virtual LAN Features |
Private VLAN, Voice VLAN, Tagged VLAN, Protocol-based VLAN, Port-based VLAN |
| Number of VLANs |
4094 |
| Fiber Ethernet Cabling Technology |
100BASE-X, 1000BASE-X |
| MAC Address Table |
16000 entries |
| Switching Capacity |
20 Gbit/s |
| Forwarding Rate |
14.9 Mpps |
| Latency (10-100 Mbps) |
7.8 µs |
| Latency (1 Gbps) |
3.4 µs |
| Static Route |
Yes |
| Jumbo Frames Support |
Yes |
| Jumbo Frames |
10000 |
| Packet Buffer Memory |
1.5 MB |
| DHCP Features |
DHCP snooping, DHCP client |
| Access Control List (ACL) |
Yes |
| IGMP Snooping |
Yes |
| Security Algorithms |
3DES, AES, MD5, PEAP, RSA, SHA-1, SHA-2, SSH, SSH-2, SSL/TLS, TTLS |
| MAC Address Filtering |
Yes |
| SSH/SSL Support |
Yes |
| Loop Protection |
Yes |
| BPDU Filtering/Protection |
Yes |
| Authentication |
MAC-based authentication, Port-based authentication, Web-based authentication |
| Root Protection |
Yes |
| Password Protection |
Yes |
| Authentication Type |
AAA, IEEE 802.1x, Network Access Control (NAC), RADIUS |
| Neighbor Discovery Snooping |
Yes |
| Multicast Support |
Yes |
| Routing Protocols |
RIP, RIP-2 |
| Rack Mounting |
Yes |
| Form Factor |
1U |
| Product Colour |
Grey |
| LED Indicators |
Yes |
| Wall Mountable |
Yes |
| Country of Origin |
China |
| Safety |
EN60950-1 (TUV), UL 60950- 1(cULus), EN60825-1 |
| Certification |
FCC Class A, EN55022 Class A, EN61000-3-2, EN61000-3-3, VCCI Class A, CISPR Class A |
| Memory Type |
DDR-SDRAM |
| Internal Memory |
512 MB |
| Flash Memory |
64 MB |
| Telnet |
Yes |
| AC Input Voltage |
100 – 240 V |
| AC Input Frequency |
50 – 60 Hz |
| Input Current |
2.4 A |
| Power Consumption (Max) |
16 W |
| Power over Ethernet (PoE) |
No |
| Operating Temperature (T-T) |
0 – 50 °C |
| Storage Temperature (T-T) |
-25 – 70 °C |
| Operating Relative Humidity (H-H) |
5 – 90% |
| Storage Relative Humidity (H-H) |
5 – 95% |
| Operating Altitude |
0 – 3000 m |
| Non-operating Altitude |
0 – 4000 m |
| Heat Dissipation |
55 BTU/h |
| Width |
265 mm |
| Depth |
180 mm |
| Height |
42.5 mm |
| Weight |
1.5 kg |
| Included Power Plug Types |
UK |
| Package Width |
430 mm |
| Package Depth |
360 mm |
| Package Height |
150 mm |
| Package Weight |
2.85 kg |
