Allied Telesis AT-x510L-28GT-50 Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey
Stackable Gigabit Edge Switch with 24 x 10/100/1000T, 4 x 1G SFP uplinks. Requires licenses to enable 10G uplink
AED5,999.00
The high-value Allied Telesis AT-x510L-28GT Gigabit edge switch features 24 x 10/100/1000T ports and 4 x 1G/10G SFP+ uplink ports with a single internal power supply. The x510L Series offers cost-effective edge connectivity for healthcare, education, and government applications. Comprehensive security and access features protect online resources, while the ability to upgrade the uplink speed and feature-set ensure a future-proof solution.
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| System event log | Y |
| MIB support | RFC1212, RFC1213, RFC1227, RFC1239, RFC1724, RFC2011, RFC2012, RFC2013, RFC2096, RFC3418, RFC3621, RFC3636, RFC2819, RFC2863 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 4 |
| Console port | RJ-45 |
| Power connector | DC-in jack |
| Networking standards | IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | N |
| Port mirroring | Y |
| Full duplex | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Spanning tree protocol | Y |
| VLAN support | Y |
| Number of VLANs | 4094 |
| MAC address table | 16000 entries |
| Switching capacity | 128 Gbit/s |
| Throughput | 95.2 Mpps |
| Latency (10-100 Mbps) | 14.4 µs |
| Latency (1 Gbps) | 4.4 µs |
| Latency (10 Gbps) | 3.1 µs |
| Jumbo frames support | Y |
| DHCP features | DHCP server, DHCP client |
| IGMP snooping | Y |
| Security algorithms | EAP-TTLS, MD5, PEAP, SSL/TLS |
| Multicast support | Y |
| Management protocols | SNMP, MLD |
| Data link protocols | LLDP |
| Supported network protocols | IGMP |
| Rack mounting | Y |
| Form factor | 1U |
| Product colour | Grey |
| LED indicators | Y |
| Safety | UL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1 |
| Certification | UL, cUL, TUV |
| Power consumption (typical) | 52 W |
| Power over Ethernet (PoE) | N |
| Operating temperature (T-T) | 0 – 45 °C |
| Storage temperature (T-T) | -25 – 70 °C |
| Operating relative humidity (H-H) | 5 – 90% |
| Storage relative humidity (H-H) | 5 – 95% |
| Operating altitude | 0 – 305 m |
| Heat dissipation | 177 BTU/h |
| Width | 440 mm |
| Depth | 325 mm |
| Height | 44 mm |
| Weight | 4.2 kg |
