Detailed Tech Specification

Output

• Nominal Output Voltage

  208V 3PH

Input

• Nominal Input Voltage

  208V 3PH

• Input frequency

  60 Hz

Physical

• Maximum Height

  24.3inches ( 616mm , 61.63CM )

• Maximum Width

  21.1inches ( 561mm , 56.15CM )

• Maximum Depth

  8.4inches ( 213mm , 21.35CM )

• Net Weight

  55.0lbs. ( 25.0KG )

• Shipping weight

  105.0lbs. ( 48.0KG )

• Shipping Height

  13.2inches ( 335mm , 33.5CM )

• Shipping Width

  26.25inches ( 667mm , 66.7CM )

• Shipping Depth

  28.3inches ( 719mm , 71.9CM )

Environmental

• Operating Temperature

  32 – 104 °F ( 0 – 40 °C )

• Operating Relative Humidity

  0 – 95 %

• Operating Elevation

  0-10000ft ( 0-3000meters )

• Storage Temperature

  0 – 45 °C

• Storage Relative Humidity

  0 – 95 %

• Storage Elevation

  0-30000ft ( 0-9000meters )

Conformance

• Approvals

  UL 1778

• Standard warranty

  1 year repair or replace
