APC Smart-UPS 3kVA RM 120V SHIPBOARD

Add to Wishlist
  • 2880VA/2700W line interactive pure sine wave 4U rack/tower UPS (rail kit AP9625 sold separately)
  • User-selectable low voltage setting of 100V-127V
  • Add up to 10 external battery packs (SMX120BP)
  • Short depth UPS provides extra space for cable management
  • Graceful shutdown using serial or USB cables via PowerChute Serial Shutdown

AED28,299.00

Add to Wishlist

This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 3kVA line interactive 4U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA L5-30P input, 6x NEMA 5-15R, 3x NEMA 5-20R and 1x NEMA L5-30R outlets. The Smart-UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms.

SKU: SMX3000RMX93 Category: Tag:
Category Attribute Value
Overview Lead time Usually in Stock
Main Product or Component Type Uninterruptible power supply (UPS)
Batteries & Runtime Run Time View Runtime Graph (action_new_window)
Efficiency View Efficiency Graph (action_new_window)
Battery Type Lead-Acid battery
Extendable Run Time 1
Included Battery Modules 0
Battery Slots Empty 0
Typical Recharge Time 3 h
RBC Quantity 1
Battery Life 3ā€¦5 year(s)
Replacement Battery APCRBC117 (action_new_window)
Battery Charge Power (Watts) 245 W rated
General Provided Equipment User’s documentation in electronic format
Number of Power Modules 0
Number of Power Module Filled Slots 0
Number of Power Module Free Slots 0
Product Web Sub-family TAA compliance
Redundant No
Physical Number of Rack Units 4U
Cable Length 8 ft (2.4 m)
Number of Cables 1
Color Black
Height 17.01 in (43.2 cm)
Width 7.01 in (17.8 cm)
Depth 19.02 in (48.3 cm)
Net Weight 85.19 lb(US) (38.64 kg)
Mounting Location Front
Mounting Preference Lower
Mounting Mode Rack-mounted
Two Post Mountable 1
USB Compatible Yes
Input Main Input Voltage 120 V
Other Input Voltage 100 V
Input Connection Type NEMA L5-30P
Efficiency at Full Load 70…153 V
Input Frequency 50/60 Hz +/- 3 Hz auto-sensing
Output Main Output Voltage 120 V
Other Output Voltage 100 V
kW Rating 2700 W
Rated Power in VA 2880 VA
Output Connection Type 3 NEMA 5-15R
Harmonic Distortion Less than 5%
Maximum Configurable Power in VA 2880 VA
Max Configurable Power (Watts) 2700 W
Transfer Time 2-4 ms
Topology Line Interactive
Wave Type Sine wave
Output Frequency (sync to mains) 50/60 Hz +/- 3 Hz sync to mains
Conformance Product Certifications BSMI
Equipment Protection Policy Lifetime: $150,000
Environmental Acoustic Level 55 dBA
Online Thermal Dissipation 276 Btu/h
Operating Altitude 0…10000 ft
Ambient Air Temperature for Operation 32ā€¦104 Ā°F (0ā€¦40 Ā°C)
Ambient Air Temperature for Storage 5ā€¦113 Ā°F (-15ā€¦45 Ā°C)
Storage Altitude 0ā€¦50000 ft (0ā€¦15240 m)
Relative Humidity 0ā€¦95 %
Storage Relative Humidity 0ā€¦95 %
