APC Smart-UPS, Line Interactive, 3kVA, Lithium-ion, Rackmount 2U, 120V, 2x NEMA 5-20R+6x NEMA 5-15R outlets, SmartConnect Port+Network Card, LCD [TAA]

2880VA/2700W line interactive pure sine wave 2U rackmount UPS

Ideal for small edge environment, back office, network infrastructure and IDF/MDF closets

Lithium-ion battery minimizes the need to replace battery during the life time of UPS

Cloud-based remote power monitoring via SmartConnect Ethernet Port

AED30,699.00

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 2880VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA L5-30P input, 6 NEMA 5-15R and 2 NEMA 5-20R outlets. It has a preinstalled Network Management Card for UPS network-based monitoring and management. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges.

SKU: SMTL3000RM2UCNCUS Category: UPS , Power Back up and accessories Tag: SMTL3000RM2UCNCUS

UPS Specifications Overview

Category	Details
Overview
Lead Time	Usually in Stock
Main Run Time for Load	2700 W, Min-Max: 270–2700 W, 5min 18s
Max Capacity Used	100%
Product Type	Uninterruptible Power Supply (UPS)

Complementary

Attribute	Details
Software Package	SmartConnect (remote monitoring, feature availability varies)

Batteries & Runtime

Attribute	Details
Run Time	View Runtime Graph
Efficiency	View Efficiency Graph
Battery Type	Li-Ion (Lithium Ion)
Battery Graph Comments	Based on actual measurements, new batteries, PF=1.0. Results may vary.
Extendable Run Time	0
Typical Recharge Time	2 hours
RBC Quantity	1
Battery Design Life	8–10 years
Battery Charge Power	216 W rated
Replacement Battery	APCRBC174-LI

General

Attribute	Details
Provided Equipment	Rack Mounting Brackets
Number of Power Modules	0
Product Web Sub-Family	Cloud-enabled monitoring
Redundant	No

Physical

Attribute	Details
Rack Units	2U
Cable Length	8 ft (2.4 m)
Color	Black with silver front bezel
Height	3.39 in (8.6 cm)
Width	17.01 in (43.2 cm)
Depth	26.89 in (68.3 cm)
Weight	75.44 lb (34.22 kg)
Mounting Preference	Lower
Mounting Mode	Rack-mounted
USB Compatible	Yes

Input

Attribute	Details
Main Input Voltage	120 V
Other Input Voltage	110 V
Input Connection Type	NEMA L5-30P
Input Protection Type	Circuit breaker
Efficiency at Full Load	82–144 V
Number of Input Connectors	1
Input Frequency	50/60 Hz ± 3 Hz auto-sensing

Output

Attribute	Details
Main Output Voltage	120 V
Other Output Voltage	110 V
kW Rating	2700 W
Rated Power (VA)	2880 VA
Output Connection Type	2 NEMA 5-20R
Crest Factor	3:1
Harmonic Distortion	<5%
Max Configurable Power (VA)	3000 VA
Max Configurable Power (Watts)	2700 W
Transfer Time	6 ms typical / 10 ms max
Topology	Line Interactive
Waveform Type	Sine Wave
Output Frequency	50/60 Hz ± 3 Hz sync to mains

Conformance

Attribute	Details
Certifications	cULus, ENERGY STAR V2.0 (USA), TAA compliant
Equipment Protection Policy	Lifetime: $150,000

Environmental

Attribute	Details
Acoustic Level	55 dB
Online Thermal Dissipation	348 Btu/h
Operating Altitude	0–10,000 ft
Operating Temp. Range	32–104°F (0–40°C)
Storage Temp. Range	5–113°F (-15–45°C)
Storage Altitude	0–25,000 ft (0–7620 m)
IP Degree of Protection	IP20
Relative Humidity (Operating)	0–95% non-condensing
Relative Humidity (Storage)	0–95% non-condensing
