APC Smart-UPS Modular Ultra 20kW Frame, N+1 Redundant, Rackmount, 208/120V

Add to Wishlist
  • Compatible with all Smart-UPS Modular Ultra models
  • External battery frame with (4) SRYLBM
  • SRYLBM included

AED154,299.00

Add to Wishlist

APC Smart-UPS Modular Ultra 20kW scalable Frame N+1 Rackmount 208/120V. Ships with no power or battery modules.

SKU: SRYLF20KRMT Category: Tag:

āš™ļø Smart-UPS Modular Ultra Frame ā€“ 20 kW Specification

Category Attribute Value
Overview Lead Time Usually in Stock
Main Main Input Voltage 208 V AC
Product or Component Type Frame
Main Output Voltage 120 V AC
kW Rating 20000 W
Rated Power in VA 20000 VA
Battery Type Li-Ion (Lithium Ion)
Range of Product Smart-UPS Modular Ultra Accessories
General Product Web Sub-Family Network management card
Number of Power Modules 2
Number of Preinstalled Modules 2
Physical Color Silver
Height 20.5 in (520 mm)
Width 17.3 in (440 mm)
Depth 29.1 in (740 mm)
Product Weight 130.3 lb (59.1 kg)
Input Input Frequency 40 ā€“ 70 Hz
Number of Input Connectors 1 Hard Wire 4-wire (2PH+N+G)
Maximum Input Current per Phase 51 A
Load Power Factor 0.5 leading to 0.5 lagging
Output Topology On-Line
Waveform Type Sine wave
Overload Operation 60s @ 125%, 30s @ 150%
Bypass Type Built-in Bypass
