APC Smart-UPS On-Line, 3kVA, Rack/Tower, 120V, 8x 5-20R+1x L5-30R NEMA outlets, SmartSlot, Extended runtime, W/O rail kit [TAA]

Add to Wishlist
  • 3kVA/2.7kW double-conversion on-line pure sine wave rack/tower UPS
  • Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
  • Rack/Tower convertible (rail kit SRTRK4 or SRTRK3 sold separately)
  • Delivers clean power with zero transfer time for critical or sensitive devices
  • Add up to 10 external battery packs (SRT96RMBP) for extended runtime

AED27,499.00

Add to Wishlist

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 3kVA on-line rack/tower UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with NEMA L5-30P input and 8x NEMA 5-20R and 1x NEMA L5-30R outlets. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown.

SKU: SRT3000XLAUS Category: Tag:

Overview

Parameter Details
Lead Time Usually in Stock

Main Specifications

Parameter Details
Main Input Voltage 120 V
Product Type Uninterruptible Power Supply (UPS)
Main Output Voltage 120 V
kW Rating 2700 W
Rated Power (VA) 3000 VA
Input Connection Type NEMA L5-30P
Output Connection Type 8× NEMA 5-20R
1× NEMA L5-30R
Cable Length 8 ft (2.4 m)
Number of Cables 1
Provided Equipment CD with software, Documentation CD, Installation guide, Removable support feet, USB cable, Warranty card
Product Range Smart-UPS On-Line

Batteries & Runtime

Parameter Details
Run Time Graph View Runtime Graph
Efficiency Graph View Efficiency Graph
Battery Type Lead-Acid battery
Extendable Run Time Yes (1)
Included Battery Modules 1
Typical Recharge Time 3 h
RBC Quantity 1
Battery Life 3–5 years
Replacement Battery APCRBC152
Battery Charge Power 151 W (rated)

General

Parameter Details
Filled Power Module Slots 0
Free Power Module Slots 0
Product Sub-family TAA compliance
Redundant No
Topology Double Conversion Online

Physical

Parameter Details
Color Black
Height 17.01 in (43.2 cm)
Width 3.35 in (8.5 cm)
Depth 25.00 in (63.5 cm)
Net Weight 69.005 lb (31.3 kg)
Mounting Location Front
Mounting Preference Lower
Mounting Mode Not rack-mountable
Mounting Position Vertical
Two Post Mountable No
USB Compatible Yes

Input

Parameter Details
Input Frequency 40–70 Hz auto-sensing

Output

Parameter Details
Bypass Type Internal Bypass (Automatic and Manual)
Crest Factor 3:1
Harmonic Distortion Less than 2%
Max Configurable Power (VA) 3000 VA
Max Configurable Power (Watts) 2700 W
Wave Type Sine wave
Output Frequency (sync to mains) 50/60 Hz ± 3 Hz

Conformance & Certifications

Parameter Details
Certifications TAA compliance, ENERGY STAR V2.0 (USA)

Environmental

Parameter Details
Acoustic Level 55 dBA
Online Thermal Dissipation 805 Btu/h
Operating Altitude 0–10,000 ft
Operating Temperature 32–104 °F (0–40 °C)
Storage Temperature 5–113 °F (-15–45 °C)
Storage Altitude 0–50,000 ft (0–15,240 m)
IP Degree of Protection IP20
Relative Humidity (Operation) 0–95% non-condensing
Relative Humidity (Storage) 0–95% non-condensing
