UPS , Power Back up and accessories
APC Smart-UPS On-Line, 3kVA, Tower, 120V, 8x 5-20R+1x L5-30R NEMA outlets, SmartSlot, Extended runtime, W/O rail kit
- 3kVA/2.7kW double-conversion on-line pure sine wave tower UPS
- Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
- Rack/Tower convertible (rail kit SRTRK4 or SRTRK3 sold separately)
- Delivers clean power with zero transfer time for critical or sensitive devices
- Add up to 10 external battery packs (SRT96RMBP) for extended runtime
AED22,899.00
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 3kVA on-line tower UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with NEMA L5-30P input and 8x NEMA 5-20R and 1x NEMA L5-30R outlets. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms.
Overview
| Attribute | Details |
|---|---|
| Presentation | High density, double-conversion on-line power protection with scalable runtime |
| Lead Time | Usually in Stock |
Main
| Attribute | Details |
|---|---|
| Main Input Voltage | 120 V |
| Product Type | Uninterruptible Power Supply (UPS) |
| Main Output Voltage | 120 V |
| Power Rating | 2700 W / 3000 VA |
| Input Connection Type | NEMA L5-30P |
| Output Connection Types | 8 × NEMA 5-20R, 1 × NEMA L5-30R |
| Cable Length | 8 ft (2.4 m) |
| Number of Cables | 1 |
| Provided Equipment | Installation guide, Removable support feet, USB cable, Warranty card |
| Range of Product | Smart-UPS On-Line |
Batteries & Runtime
| Attribute | Details |
|---|---|
| Run Time | View Runtime Graph |
| Efficiency | View Efficiency Graph |
| Battery Type | Lead-Acid battery |
| Battery Voltage | 96 V |
| Extendable Run Time | Yes (1) |
| Included Battery Modules | 1 |
| Typical Recharge Time | 3 hours |
| RBC Quantity | 1 |
| Battery Life | 3–5 years |
| Replacement Battery | APCRBC152 |
| Battery Charge Power | 151 W rated |
General
| Attribute | Details |
|---|---|
| Power Module Filled Slots | 0 |
| Power Module Free Slots | 0 |
| Web Sub-Family | High density |
| Redundant | No |
| Topology | Double Conversion Online |
Physical
| Attribute | Details |
|---|---|
| Color | Black |
| Height | 3.35 in (8.5 cm) |
| Width | 17.01 in (43.2 cm) |
| Depth | 25.00 in (63.5 cm) |
| Net Weight | 69.005 lb (31.3 kg) |
| Mounting Location | Front |
| Mounting Preference | Lower |
| Mounting Mode | Not rack-mountable |
| Two Post Mountable | No (0) |
| Mounting Position | Vertical |
| USB Compatible | Yes |
Input
| Attribute | Details |
|---|---|
| Input Frequency | 40–70 Hz (auto-sensing) |
Output
| Attribute | Details |
|---|---|
| Bypass Type | Internal Bypass (Automatic & Manual) |
| Crest Factor | 3:1 |
| Harmonic Distortion | Less than 2% |
| Max Configurable Power | 2700 W / 3000 VA |
| Wave Type | Sine wave |
| Output Frequency (Sync to Mains) | 50/60 Hz ± 3 Hz |
Conformance
| Attribute | Details |
|---|---|
| Certifications | ENERGY STAR V2.0 (USA) |
Environmental
| Attribute | Details |
|---|---|
| Acoustic Level | 55 dBA |
| Online Thermal Dissipation | 805 Btu/h |
| Operating Altitude | 0–10,000 ft |
| Operating Temperature | 32–104 °F (0–40 °C) |
| Storage Temperature | 5–113 °F (-15–45 °C) |
| Storage Altitude | 0–50,000 ft (0–15,240 m) |
| IP Degree of Protection | IP20 |
| Relative Humidity (Operating/Storage) | 0–95% (non-condensing) |
