04 3550600 052 7036860

APC Smart-UPS On-Line, 6kVA/6kW, Rackmount 6U, 208V, 12x 5-20R+2x L6-20R+2x L6-30R NEMA, Network Card+SmartSlot, W/ transformer 208V-120V, W/ rail kit

Add to Wishlist
  • 6kVA/6kW double-conversion on-line pure sine wave 6U rackmount UPS
  • Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
  • Rack/Tower convertible (rail kit included)
  • Add up to 10 external battery packs (SRT192RMBP) for extended runtime

AED54,799.00

Add to Wishlist

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 6kVA on-line 6U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire (2P+E) input, 12x NEMA 5-20R, 2x NEMA L6-20R and 2x NEMA L6-30R outlets. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms.

SKU: SRT6KRMXLT-5KTF Category: Tag:

Overview

Attribute Value
Lead Time Usually in Stock

Main

Attribute Value
Run Time for Load 6000 W (Min-max: 600–6000 W) — 2 min 17 s
Max. Capacity Used 100%
Main Input Voltage 208 V
Product or Component Type Uninterruptible Power Supply (UPS)
Main Output Voltage 120 V
kW Rating 6000 W
Rated Power in VA 6000 VA
Output Connection Type 12 NEMA 5-20R, 2 NEMA L6-20R, 2 NEMA L6-30R
Output Connector Type 1 Hard Wire 3-wire (2PH + G)
Number of Rack Units 6U
Provided Equipment CD with software, Documentation CD, Installation guide, Rack mounting hardware, Rack Mounting brackets, Rack Mounting support rails, Temperature Probe, USB cable, Warranty card, Web/SNMP Management Card
Range of Product Smart-UPS On-Line

Batteries & Runtime

Attribute Value
Battery Type Lead-Acid battery
Battery Voltage 192 V
Extendable Run Time 1
Included Battery Modules 0
Battery Slots Empty 0
Typical Recharge Time 1.5 h
RBC Quantity 1
Battery Life 3–5 years
Replacement Battery APCRBC140
Battery Charge Power 579 W rated

General

Attribute Value
Number of Power Module Filled Slots 0
Number of Power Module Free Slots 0
Product Web Sub-family High Density
Redundant No
Topology Double Conversion Online

Physical

Attribute Value
Color Black
Height 10.35 in (26.3 cm)
Width 17.01 in (43.2 cm)
Depth 28.31 in (71.9 cm)
Net Weight 230.008 lb (104.33 kg)
Mounting Location Front
Mounting Preference Lower
Mounting Mode Rack-mounted
Two Post Mountable No
USB Compatible Yes
Mounting Position Horizontal

Input

Attribute Value
Efficiency at Full Load 100…275 V adjustable (half load)
Number of Input Connectors 1 Hard Wire 3-wire (2PH + G)
Input Frequency 40–70 Hz auto-sensing

Output

Attribute Value
Bypass Type Internal Bypass (Auto and Manual)
Crest Factor 3:1
Harmonic Distortion Less than 2%
Maximum Configurable Power in VA 6000 VA
Max Configurable Power (Watts) 6000 W
Wave Type Sine wave
Output Frequency (sync to mains) 50/60 Hz ± 3 Hz

Conformance

Certifications
ENERGY STAR V2.0 (USA)
FCC part 15 class A
UL 1778

Environmental

Attribute Value
Acoustic Level 55 dBA
Online Thermal Dissipation 1402 Btu/h
Operating Altitude 0…10,000 ft
Ambient Air Temp (Operation) 32–104 °F (0–40 °C)
Ambient Air Temp (Storage) 5–113 °F (-15–45 °C)
Storage Altitude 0…50,000 ft (0–15,240 m)
IP Degree of Protection IP20
Relative Humidity (Operation/Storage) 0–95% non-condensing
