APC Smart-UPS On-Line, 8kVA/8kW, Rackmount 6U, 208V, 4x L6-20R+2x L6-30R NEMA outlets, Network Card+SmartSlot, Extended runtime, W/ rail kit
- 8kVA/8kW double-conversion on-line pure sine wave 6U rackmount UPS
- Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
- Rack/Tower convertible (rail kit included)
- Add up to 10 external battery packs (SRT192RMBP2) for extended runtime
AED59,899.00
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 8kVA on-line 6U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with Hard Wire 3-wire (2P+E) input, 4x NEMA L6-20R and 2x NEMA L6-30R outlets. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms.
| Category | Specification |
|---|
| Overview |
| Lead time | Usually in Stock |
| Main |
| Main Input Voltage | 208 V |
| Product or Component Type | Uninterruptible power supply (UPS) |
| Other Input Voltage | 240 V |
| Main Output Voltage | 208 V |
| Other Output Voltage | 240 V |
| Kw Rating | 8000 W |
| Rated power in VA | 8000 VA |
| Output connection type | 4 NEMA L6-20R, 2 NEMA L6-30R |
| Output connector type | Hard Wire 3-wire (2PH + G) |
| Number of rack unit | 6U |
| Provided equipment | CD with software, Documentation CD, Installation guide, Rack mounting hardware, Rack Mounting brackets, Rack Mounting support rails, Temperature Probe, USB cable, Warranty card, Web/SNMP Management Card |
| Range of Product | Smart-UPS On-Line |
| Batteries & Runtime |
| Run Time | View Runtime Graph (action_new_window) |
| Efficiency | View Efficiency Graph (action_new_window) |
| Battery Type | Lead-Acid battery |
| Battery Voltage | +/-192 V (split battery referenced to neutral) |
| Extendable Run Time | Yes (1) |
| Included Battery Modules | 0 |
| Typical recharge time | 1.5 h |
| RBC Quantity | 2 |
| Battery life | 3–5 year(s) |
| Replacement battery | APCRBC140 (action_new_window) |
| Battery Charge Power (Watts) | 1136 W rated |
| General |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Product web sub-family | High density |
| Redundant | No |
| Topology | Double Conversion Online |
| Physical |
| Color | Black |
| Height | 10.35 in (26.3 cm) |
| Width | 17.01 in (43.2 cm) |
| Depth | 28.15 in (71.5 cm) |
| Net Weight | 245.99 lb (111.58 kg) |
| Mounting Location | Front |
| Mounting preference | No preference |
| Mounting Mode | Rack-mounted |
| Two post mountable | 0 |
| USB compatible | Yes |
| Input |
| Efficiency at full load | 100…275 V adjustable (half load) |
| Number of input connectors | 1 Hard Wire 3-wire (2PH + G) |
| Input Frequency | 40 – 70 Hz auto-sensing |
| Output |
| Bypass type | Internal Bypass (Automatic and Manual) |
| Crest factor | 3 : 1 |
| Harmonic distortion | Less than 2% |
| Maximum configurable power in VA | 8000 VA |
| Max Configurable Power (Watts) | 8000 W |
| Wave type | Sine wave |
| Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz sync to mains |
| Conformance |
| Product Certifications | ENERGY STAR V2.0 (USA), FCC part 15 class A, NOM, UL 1778 |
| Environmental |
| Acoustic level | 55 dBA |
| Online Thermal Dissipation | 1712 Btu/h |
| Operating altitude | 0…10000 ft |
| Ambient air temperature for operation | 32…104 °F (0…40 °C) |
| Ambient Air Temperature for Storage | 5…113 °F (-15…45 °C) |
| Storage altitude | 0…50000 ft (0…15240 m) |
| IP degree of protection | IP20 |
| Relative Humidity | 0…95 % non-condensing |
| Storage Relative Humidity | 0…95 % non-condensing |
