AED47,499.00
Smart-UPS On-Line provides high-density, true double-conversion online power protection for servers, voice/data networks, medical labs, and light industrial applications. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute™ management software provides unattended graceful shutdown of network operating systems. All models 6kVA and above include an integrated network management card for remote management (optional on models below 6kVA). The entire Smart-UPS On-Line family provides value to customers with demanding power conditions, including a very wide input voltage window, extremely tight output voltage regulation, internal bypass, and input power factor correction.
| Category | Specification |
|---|
| Overview |
| Lead time | Usually in Stock |
| Main |
| Main Input Voltage | 208 V |
| Other Input Voltage | 240 V |
| Product or Component Type | Uninterruptible power supply (UPS) |
| Main Output Voltage | 120 V, 208 V |
| Other Output Voltage | 240 V |
| kW Rating | 4200 W |
| Rated power in VA | 6000 VA |
| Input Connection Type | NEMA L14-30P |
| Output Connection Type | 4 NEMA 5-20R, 1 NEMA L6-30R, 1 NEMA L14-30R |
| Number of rack unit | 3U |
| Cable length | 10 ft (3.05 m) |
| Number of cables | 1 |
| Provided equipment | CD with software, Rack Mounting support rails, Removable support feet, Smart UPS signalling RS-232 cable, User Manual |
| Range of Product | Smart-UPS On-Line |
| Batteries & Runtime |
| Battery Type | Lead-Acid battery |
| Extendable Run Time | 1 |
| Included Battery Modules | 2 |
| Typical recharge time | 2.5 h |
| RBC Quantity | 1 |
| Battery life | 3…5 year(s) |
| Replacement battery | APCRBC140 |
| Battery Charge Power (Watts) | 382 W rated |
| General |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Redundant | No |
| Topology | Double Conversion Online |
| Physical |
| Color | Black |
| Height | 5.12 in (13 cm) |
| Width | 17.01 in (43.2 cm) |
| Depth | 25.98 in (66 cm) |
| Net Weight | 128.0005 lb (58.06 kg) |
| Mounting Location | Front |
| Mounting preference | Lower |
| Mounting Mode | Rack-mounted |
| Two post mountable | 0 |
| USB compatible | No |
| Input |
| Efficiency at full load | 85…136 V adjustable, 156…236 V |
| Input Frequency | 50/60 Hz +/- 5 Hz auto-sensing |
| Output |
| Bypass type | Internal Bypass (Automatic and Manual) |
| Crest factor | 3 : 1 |
| Harmonic distortion | Less than 2% |
| Maximum configurable power in VA | 6000 VA |
| Max Configurable Power (Watts) | 4200 W |
| Wave type | Sine wave |
| Efficiency at full load | 90 % |
| Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 |
| Additional information | Configurable for 208 or 240 nominal output voltage |
| Conformance |
| Product Certifications | CSA |
| Environmental |
| Acoustic level | 55 dBA |
| Online Thermal Dissipation | 1780 Btu/h |
| Operating altitude | 0…10000 ft |
| Ambient air temperature for operation | 32…104 °F (0…40 °C) |
| Ambient Air Temperature for Storage | 5…113 °F (-15…45 °C) |
| Storage altitude | 0…50000 ft (0…15240 m) |
| IP degree of protection | IP20 |
| Relative Humidity | 0…95 % non-condensing |
| Storage Relative Humidity | 0…95 % non-condensing |
