APC Smart-UPS SRT Step-Down Transformer, 10kVA, rackmount, 4U, 2x NEMA L5-20R & 2x NEMA L14-30R outlets
AED16,099.00
| Category | Specification |
|---|
| Overview |
| Lead time | Usually in Stock |
| Main |
| Main Input Voltage | 208 V |
| Product or Component Type | Transformer |
| Main Output Voltage | 120 V, 208 V, 240 V |
| Output connector type | 2 Hard Wire 3-wire (2PH + G), 1 Hard Wire 4-wire (2PH+N+G) |
| Provided Equipment | Mounting Hardware, Rack Mounting brackets, Safety guide, User Manual, Warranty card |
| Range of Product | Smart-UPS Accessories |
| Physical |
| Color | Black |
| Height | 6.85 in (17.4 cm) |
| Width | 17.01 in (43.2 cm) |
| Depth | 29.49 in (74.9 cm) |
| Net Weight | 220.00 lb (99.79 kg) |
| Mounting preference | Lower |
| Mounting Mode | Rack-mounted |
| Mounting position | Horizontal |
| Input |
| Permissible voltage | 200…240 V |
| Max line current | 60 A |
| Input current limits | 60 A |
| Load Capacity | 10000 VA |
| Input Frequency | 45…65 Hz |
| Number of input connectors | 1 Hard Wire 3-wire (2PH + G) |
| Output |
| Maximum Total Current Draw per Phase | 60 A |
| Number of power socket outlets | 4 |
| Power socket outlets details | 2 NEMA L5-20R, 2 NEMA L14-30R |
| Conformance |
| Product Certifications | CE, CSA, UL Listed |
| Environmental |
| Ambient air temperature for operation | 32…104 °F (0…40 °C) |
| Relative Humidity | 0…95 % non-condensing |
| Operating altitude | 0…10000 ft |
| Ambient Air Temperature for Storage | 5…113 °F (-15…45 °C) |
| Storage Relative Humidity | 0…95 % non-condensing |
| Storage altitude | 0…50000 ft (0…15240 m) |
