| Overview |
Lead Time |
Special Order – Call for Quoted Lead Times |
|
Max. Capacity Used |
100% |
|
Run Time for Load (6400W) |
5 min 56 s |
|
Load Min-Max |
640 – 6400 W |
|
Product Type |
Uninterruptible Power Supply (UPS) |
|
Main Input Voltage |
208 V |
|
Main Output Voltage |
120 V, 208 V |
|
Other Output Voltage |
240 V |
|
Rated Power (Watts) |
6400 W |
|
Rated Power (VA) |
8000 VA |
|
Output Connector Type |
Hard Wire 4-wire (2PH+N+G) |
| Batteries & Runtime |
Battery Type |
Lead-Acid battery |
|
Run Time |
View Runtime Graph |
|
Efficiency |
View Efficiency Graph |
|
Included Battery Modules |
2 |
|
Battery Slots Empty |
2 |
|
Extendable Run Time |
0 |
|
Typical Recharge Time |
3 h |
|
Battery Life |
3–5 years |
|
Battery Charge Power |
574 W rated |
|
Additional Info |
Configurable for 200, 208, or 220V 3 Phase nominal output voltage |
| General |
Provided Equipment |
CD with software, Installation guide, User Manual, Web/SNMP Management Card |
|
Power Module Free Slots |
3 |
|
Power Module Filled Slots |
2 |
|
Redundant |
No |
| Physical |
Height |
36.89 in (93.7 cm) |
|
Width |
19.02 in (48.3 cm) |
|
Depth |
28.58 in (72.6 cm) |
|
Product Weight |
482.99 lb (219.08 kg) |
|
Mounting Preference |
No preference |
|
Mounting Mode |
Not rack-mountable |
|
Two Post Mountable |
0 |
|
USB Compatible |
No |
| Input |
Number of Input Connectors |
1 Hard Wire 3-wire (1PH+N+G) |
| Output |
Max Configurable Power (Watts) |
12,800 W |
|
Max Configurable Power (VA) |
16,000 VA |
|
Output Frequency |
47–63 Hz sync to mains
60 Hz ± 0.1% (unsynced) |
|
Crest Factor |
Up to 5:1 |
|
Topology |
Double Conversion Online |
|
Waveform Type |
Sine wave |
|
Bypass Type |
Internal Bypass (Automatic and Manual) |
|
Max Output Current |
37 A |
| Conformance |
Standards |
FCC Part 15 Class A, UL 1778 |
| Environmental |
Operating Temperature |
32–104 °F (0–40 °C) |
|
Storage Temperature |
5–113 °F (-15–45 °C) |
|
Operating Altitude |
0–10,000 ft |
|
Storage Altitude |
0–15,000 ft (0–4,572 m) |
|
Relative Humidity (Operating & Storage) |
0–95% |
|
Acoustic Level |
62 dBA |
|
Online Thermal Dissipation |
5 Btu/h |
