| Model: | ASA 5500-X Series Next-Generation Firewalls with firepower services |
| Detail: |
Cisco ASA 5500-X Next Generation, ASA 5508-X, 8*GE ports, 1GE Mgmt, AC, 3DES/AES, AVC, FirePower, FireSIGHT
|
ASA5508-K9 Overview
Cisco ASA 5508-X FirePower services Firewall is the entry-level next-generation firewall system.It is designed for small or mid-size enterprise or branch offices. It provides 8 Gigabit Ethernet interfaces,80GB SSD, supports up to 100 IPsec VPN peers, 50,000 concurrent connections and 1 Gbps thoughtput.
Quick Specs
Figure 1 shows the appearance of ASA5508-K9.
Table 1 shows the Quick Specs.
| Product Code | ASA5508-K9 |
| Interfaces | 8 x 1 Gigabit Ethernet interface,1 management port |
| Stateful inspection throughput (multiprotocol) | 500 Mbps |
| Maximum 3DES/AES VPN throughput | 175 Mbps |
| IPsec site-to-site VPN peers | 100 |
| Virtual interfaces (VLANs) | 50 |
| Memory | 8GB |
| Flash | 8GB |
| Power (AC or DC) | AC Only |
| Height (rack units) | 1RU |
| Dimensions (D x H x W) | 11.288 in xĀ 1.72 in xĀ 17.2 in |
| Package Weight | 8.77 Kg |
Product Details
Figure 2 shows the front panel of ASA5508-K9.
Table 2 shows the description of Status LED on the front panel.
| Number | LED | Color | Description |
| ā | Power | Unlit | Power supply off |
| Solid Green | Power supply on | ||
| ā” | Status | Green | Normal system function. |
| Amber | Critical alarm indicating one or more of the following:
Ā·Major failure of a hardware or software component. Ā·Over-temperature condition. Ā·Power voltage outside the tolerance range. |
||
| ā¢ | Active | Solid Green | Failover pair operating normally. |
| Unlit | Failover is not operational. | ||
| ā£ | SSD | Unlit | No SSD present. |
| Green | Activity on the drive. |
Figure 3 shows the back panel of ASA5508-K9.
Noteļ¼
| ā | Power switch | ā„ | SSD LED |
| ā” | Power cord socket | ā¦ | SSD bay |
| ā¢ | Status LEDs | ā§ | USB port |
| ā£ | Console ports | āØ | Management port |
| ā¤ | Reset button | ā© | Network data ports |
Ā· Console ports are two serial ports, a mini USB Type B, and a standard RJ-45 (8P8C).
Ā· Management port connects with an RJ-45 cable.
Ā· Network data ports include eight Gigabit Ethernet RJ-45 (8P8C) network I/O interfaces.
Figure 4 shows the unboxing view of ASA5508-K9.
Figure 5 shows the accessories with ASA5508-K9.
Compare to Similar Items
Table 4 shows the comparison of ASA5506-K9, ASA5508-K9 and ASA5515-K9.
| Models | ASA5506-K9 | ASA5508-K9 | ASA5515-K9 |
| Interfaces | 8 x 1 GE | 8 x 1 GE | 6 GE Copper |
| Stateful Inspection Throughput
(multiprotocol) |
300 Mbps | 500 Mbps | 1.2 Gbps |
| Maximum 3DES/AES VPN Throughput | 100 Mbps | 175 Mbps | 250 Mbps |
| Memory | 4GB | 8GB | 8GB |
| Flash | 8GB | 8GB | 8GB |
| Height (rack units) | Desk Top | 1 RU | 1 RU |
ASA5508-K9 Specification
ASA5508-K9 Specifications |
|
| Type | Cisco ASA 5508-X w/ FirePOWER Services |
| Throughput:
Application Control (AVC) |
450 Mbps |
| Throughput:
Application Control (AVC) and IPS |
250 Mbps |
| Maximum concurrent sessions | 100,000 |
| Maximum New Connections per second | 10,000 |
| Supported applications | More than 3,000 |
| URL categories | 80+ |
| Number of URLs categorized | More than 280 million |
| Centralized configuration, logging, monitoring, and reporting | Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center |
| On-Device Management | ASDM (version 7.3 or higher required) |
| Feature | Cisco ASA 5508-X w/ FirePOWER Services |
| Stateful inspection throughput (maximum) | 1 Gbps |
| Stateful inspection throughput (multiprotocol) | 500 Mbps |
| Triple Data Encryption Standard/ Advanced Encryption Standard (3DES/AES) VPN throughput3 |
175 Mbps |
| Users/nodes | Unlimited |
| IPsec site-to-site VPN peers | 100 |
| Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections5 | 100 |
| Virtual interfaces (VLANs) | 50 |
| Security contexts5(included; maximum) | 2; 5 |
| High availability | Active/ Active and Active/ Standby |
| Integrated Wireless Access Point
(See Cisco AP 702 datasheet for WiFi technical details) |
N/A |
| Expansion slot | N/A |
| User-accessible Flash slot | No |
| USB 2.0 ports | USB port type āAā, High Speed 2.0 |
| Integrated I/O | 8 x 1GE |
| Expansion I/O | N/A |
| Dedicated management port | Yes (To be shared with FirePOWER Services), 10/100/1000 |
| Serial ports | 1 RJ-45 and Mini USB console |
| Solid-state drive | 80 GB mSata |
| Memory | 8 GB |
| System flash | 8 GB |
| System bus | Multibus architecture |
| Temperature | 32 to 104Ā°F (0 to 40 Ā°C) |
| Relative humidity | 10 to 90 percent noncondensing |
| Altitude | Designed and tested for 0 to 10,000 ft (3048 m) |
| Acoustic noise |
Ā 41.6 A-weighted decibels (dBA) type |
| 67.2 dBA max | |
| Temperature | -13 to 158ĀŗF (-25 to 70ĀŗC) |
| Relative humidity | 10 to 90 percent noncondensing |
| Altitude | Designed and tested for 0Ā to 15,000 ft (4572 m) |
| AC range line voltage | External, 90 to 240 volts alternating current (VAC) |
| AC normal line voltage | 91 to 240 VAC |
| AC current | 0.25AC amps |
| AC frequency | 50/60 Hz |
| Dual-power supplies | None |
| DC domestic line voltage | N/A |
| DC international line voltage | N/A |
| DC current | N/A |
| Steady state | 12V @3.0A |
| Maximum peak |
12V @ 5A |
| Maximum heat dissipation |
123 Btu/hr |
| Form factor | 1 rack unit (RU), 19-in. rack-mountable |
| Dimensions
(HĀ xĀ W x D) |
1.72 x 17.2 x 11.288 in. |
| (4.369 x 43.688 x 28.672 cm) | |
| Weight (with AC power supply) | 8 lb (3 kg) |
