ATEN CE600 DVI KVM Extender with Audio

Add to Wishlist

AED2,699.90

Add to Wishlist

ATEN CE600 Overview

The Aten CE600 DVI KVM Extender is a DVI and USB based KVM Extender with RS-232 serial functionality. It allows access to a computer system from a remote console (USB keyboard, monitor, and mouse), gearing it towards use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location – away from the dust and dirt of the factory floor, or the harsh environmental influence of a construction site, for example. This allows you to deploy system equipment over large distances. The CE600 users one Cat 5e cable (DVI Single Link) to support up to 1920 x 1200 video resolution. The 2nd Cat 5e cable is used for HDCP, RS-232, and microphone signals.

Local and remote units connect at distances up to 200′ using Cat 5e cable
Allows access to a computer or KVM installation from a remote console up to 200′ away
Allows A/V transmission over one Cat 5e cable
The 2nd Cat 5e cable is used for HDCP, RS-232, and microphone signals
RS-232 serial ports – connect to a serial terminal, or serial devices such as touchscreens and barcode scanners (Baud rate 115200 bps)
Audio enabled – supports stereo speakers and microphone
Pushbutton operating mode selection (local unit only) – select between local and auto operating modes, with the press of a single button
Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
Supports widescreen formats
Up to 1920 x 1200 @ 60 Hz at 100′; 1024 x 768 @ 60 Hz at 200′
Hot pluggable
Rack mountable
No software required – connecting cables to the devices is all it takes
Category: Tag:

ATEN CE600 Specs

Supported Operating Systems Windows: 2000, 2003, 2008, XP, Vista, 7
Linux: Redhat 9.0 and up; SuSE 10, 11.1 and up; Debian 3.1, 4.0; Ubuntu 7.04, 7.10
UNIX: FreeBSD 5.5, 6.1, 6.2
Novell: Netware 6.0 and up
Connectors Local:
DVI-D female
Mini stereo jack female Speaker (green)
Mini stereo jack female Mic (pink)
USB Type B female
DB9 for RS-232
2 x RJ-45 female
Remote:
USB Type A Female Keyboard
DVI-D female
USB Type A female Mouse
Mini stereo jack female Speaker (green)
Mini stereo jack female Mic (pink)
DB9 for RS-232
2 x RJ-45 female
LED Indicator 1 x link, 1 x power on both local and remote
Switches Remote: 1 x 8-position EQ switch
Local: 1 x firmware upgrade slide switch
Emulation Keyboard/mouse: USB
Video Resolution 1920 x 1200 @ 60Hz (30 m)
1024 x 768 @ 60Hz (60 m)
Power Consumption Local: DC 5.3 V/2.65 W
Remote: DC 5.3 V/4.24 W
Operating Temperature & Humidity 32 – 122°F (0 – 50°C), RH 0 – 80% non-condensing
Storage Temperature -4 – 140°F (-20 – 60°C)
Housing Material Metal
Dimensions Local: 8.0 x 3.4 x 1.0″ (20.2 x 8.5 x 2.5 cm)
Remote: 8.0 x 3.4 x 1.0″ (20.2 x 8.5 x 2.5 cm)
Weight Local: 16.93 oz (0.48 kg)
Remote: 16.93 oz (0.48 kg)
Packaging Info
Package Weight 4.4 lb
Box Dimensions (LxWxH) 13 x 8.3 x 3.8″
