ATEN HDMI HDBaseT Extender over CATx Cable with PoH (328′)

Add to Wishlist

AED229,999.00

Add to Wishlist

ATEN VE1812 Overview

The VE1812 HDMI HDBaseT Extender with POH is the ideal solution for connecting equipment in remote locations up to 100m over a single Cat 5e / 6 / 6a cable. With Long Reach Mode enabled, the VE1812 can extend HDMI signal up to 150m @1080p. The VE1812 supports RS-232 and IR signaling pass-through, allowing you to control the HDMI source device from the receiver unit (VE1812R) while also accessing the HDMI display device from the transmitter unit (VE1812T). The IR signals can also be extended in both directions. The VE1812 features Power over HDBaseT (POH) which sends power from Tx to Rx over Cat 5e / 6 / 6a cable without any additional power supply. The VE1812 is HDMI (3D, Deep Color, 4kx2k) and HDCP compatible. When transmitting HDMI / 4K with a Cat 6a or ATEN 2L-2910 Cat 6 cable, the maximum distance can reach up to 100 meters. The VE1812 is perfect for digital classrooms, video conference rooms, gaming or any installation that requires superior video quality.

Key Features
  • HDBaseT Connectivity – extends an HDMI connection over a long distance via one Cat 5e / 6 / 6a cable
  • Supports HDBaseT Long Reach Mode – Up to a maximum range of 150 meters @ 1080p
  • 4k x 2k HDMI transmission distance up to 100m over Cat 6a or ATEN 2L-2910 Cat 6 cable
  • HDBaseT Anti-jamming – resists signal interference during high – quality video transmission using HDBaseT technology
  • POH (Power over HDBaseT) – supplies power from Transmitter to Receiver over a long distance via one Cat 5e / 6 / 6a cable
  • Bi-directional RS-232 channel – allows you to connect to serial terminals or serial devices, such as touch screens and barcode scanners
SKU: VE1812 Category: Tag:

ATEN VE1812 Specs

General
Device Type Video/audio/infrared extender
Form Factor Rack-mountable
Networking
Connectivity Technology Wired
Data Link Protocol HDBaseT
Data Transfer Rate 10.2 Gbps
Max Resolution 4096 x 2160 @ 60 Hz
Max Transfer Distance 492 ft
Features HDCP compliant, 3D support, 4K resolution support, 2K resolution support, metal housing, 1080p resolution support
Expansion / Connectivity
Interfaces 1 x HDMI – 19 pin HDMI Type A
1 x RS-232 – terminal block
1 x IR
1 x HDBaseT – RJ-45
Miscellaneous
Included Accessories IR receiver, IR transmitter, 2 x RS-232 terminal blocks
Compliant Standards RoHS, CEC
Power
Power Over Ethernet (PoE) PoH
Power Device External power adapter
Dimensions & Weight
Width 4 in
Depth 5.4 in
Height 1.1 in
Weight 15.87 oz
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range Operating 0 – 80% (non-condensing)
