AVer TR335 30x 4K Auto Tracking PTZ Camera

Add to Wishlist

Quick tech specs

  • 3 Auto Tracking Modes
  • 3G-SDI, HDMI, IP, USB Output
  • 8MP Picture
  • Tally Light
  • 30x Optical Zoom
  • 4K Resolution
  • Wide Dynamic Range

AED19,099.00

Add to Wishlist
Category Details
Overview
Brand AVer
Product Line AVer
Model TR335
Manufacturer AVer
Network & Communication
Host Interface USB 3.0
Network Interface Ethernet 10Base-T/100Base-TX/1000Base-T
Protocols ARP, CGI, DHCP, HTTP, IGMP, ICMP, IPv4, IPv6, RTCP, RTMP, RTP, RTSP, TCP/IP, UDP/IP
Connectivity
Connectivity Technology Wired
Ports 3G-SDI – BNC, Audio line-in/microphone, HDMI, LAN/power – RJ-45, Serial RS-232, Serial RS-422, USB 3.0 – 9 pin USB Type B
Display & Graphics
Image Sensor Size 1/2.8″
Image Sensor Type CMOS
Tilt -30 to +90 degrees
Touchscreen No
Video
Audio Formats AAC-LC
Audio Support Yes
Camera Mechanical Design Pan / Tilt / Zoom
Control Interface RS-232, RS-422, VISCA
Digital Zoom 12x
Horizontal Resolution 1400 TV lines
Max Frame Rate 60 frames per second
Max Panning Speed 200 degrees/second
Max Tilting Speed 200 degrees/second
Max Video Resolution 3840 x 2160 (4K)
Panning Range -170 to +170 degrees
Shutter Speed (Max) 1/10000 second
Shutter Speed (Min) 1 second
Video Modes 1080/25p, 1080/29.97PsF, 1080/30p, 1080/50p, 1080/59.94p, 1080/60p, 4K/25p, 4K/29.97p, 4K/30p, 4K/50p, 4K/59.94p, 4K/60p, 720/25p, 720/30p, 720/50p, 720/59.94p, 720/60p
Video Signals 3G-SDI, HDMI, USB
Camera
Camera Mount Type Ceiling mount
Camera Type Conference camera
Power
Low Voltage Power DC 12V / PoE Plus
Power Consumption 18 watts
Power Device Type Power adapter
Software
Software Certification Zoom Certified
Technical Information
Angular Field of View (D, Max) 69.2 degrees
Angular Field of View (D, Min) 2.8 degrees
Angular Field of View (H, Max) 62.3 degrees
Angular Field of View (H, Min) 2.5 degrees
Angular Field of View (V, Max) 37.3 degrees
Angular Field of View (V, Min) 1.4 degrees
Power Device Form Factor External
Focal Length Control Motorized zoom
Focus Modes Automatic, Manual
Indoor/Outdoor Indoor
Lens Aperture F/1.6-4.8
Max Focal Length 46.8 mm
Min Focal Length 3.9 mm
Min Focus Distance 3.9 inch
Max Operating Temperature 104°F
Min Operating Temperature 32°F
Minimum Illumination 0.5 lux (F/1.6 – 50 IRE – shutter 1/30 sec / AGC on)
Operating Humidity 20 – 80%
Optical Zoom 30x
Sensor Size (metric) 9.1 mm (1/2.8″)
Total Pixels 8,000,000 pixels
Video Formats H.264, H.265, MJPEG
Video Input Color
Product Information
Features 256 preset positions, 2D/3D Noise Reduction, Auto tracking, Backlight Compensation, Barco ClickShare compatible, Image flip/mirror, Intel Unite compatible, Manual exposure, NDI
Packaged Quantity 1
Security Slot Type Kensington security slot
Theft Protection Security lock slot (cable lock sold separately)
Included Items
Cables 1 x DB-9 to DIN-8 cable (external), 1 x RS-232 cable (external)
Included Accessories Cable fixing plates, Cable ties, Ceiling mount kits, Drilling paper, Remote control, Screws
Dimensions & Weight
Height 7.6 inch
Weight 4.41 lbs
Width 7.1 inch
Depth 5.7 inch
Physical Characteristics
Color Category Black
Certifications & Listings
Compliant Standards IEEE 802.3at
ENERGY STAR Certified No
EPEAT Compliant No
TAA Compliant Yes
TCO Certified No
