Blonder Tongue Clearview 4:2 12 Program HD 1080 Transcoder with Audio Passthrough & COM3000

Add to Wishlist
  • Decrypts AES-128 encrypted H.264 video content
  • IP input that supports up to 12 SPTS H.264 HD programs
  • IP output supports up to 12 SPTS MPEG-2 HD programs
  • Preserves embedded watermarking on outbound MPEG-2 video content
  • Easy-to-use GUI for monitoring & control

د.إ26,499.00

Add to Wishlist

The Clearview 4:2 12 can Transcode up to twelve (12) HD or SD programs from H.264 (MPEG-4) to MPEG-2 in 1RU. The unit accepts Unicast H.264 IP transport streams and re-encodes the video content to SD MPEG-2 transport streams for IP Unicast delivery.

The Clearview 4:2 12 can be configured to receive up to twelve (12) H.264 AES-128 encrypted IP channels from Technicolor COM3000/2000 satellite receivers. The Clearview 4:2 12 decrypts the AES-128 content and Transcodes the decrypted H.264 content into MPEG-2, while preserving the DirecTV “forensic watermarking” and returns the content to the Technicolor COM3000/2000 devices.

  • Features:

    • Decrypts AES-128 encrypted H.264 video content
    • IP input that supports up to 12 SPTS H.264 HD programs
    • IP output supports up to 12 SPTS MPEG-2 HD programs
    • Preserves embedded watermarking on outbound MPEG-2 video content
    • Easy-to-use GUI for monitoring & control
    • 12 front panel Status LEDs, one for each program stream
    • One front panel Temperature LED
SKU: CLEARVIEW 4:2-12 Category: Tag:

  • Specifications:

    • Input
    • Connectors: 1 x Front Panel RJ45 (IP Video Port, Input/Output)
    • Standard Protocols Supported: UDP/IP
    • Standard: 1000Base-T (GbE)
    • TS Packet Length: 188 bytes
    • Sync Byte: 0x47
    • Decryption: AES-128
    • TS Supported: 12 SPTS
    • Video Resolution:
      480i (30 FPS)
      720p (60 FPS)
      1080i (30 FPS)
      1080p (30/60 FPS)
    • Audio: Pass-through
    • Routing Protocol: Unicast

      Alarms & Monitoring

    • Local Monitoring:
      1x Power LED
      1x Temperature LED
      12x Status LEDs
    • Local Control: 1x IP Reset button
    • Remote Control: 1x RJ45 (1000Base-T GbE)

      Output

    • Connector: 1 x Front Panel RJ45 (IP Video Port, Input/Output)
    • Standard: 1000Base-T (GbE)
    • Protocols Supported: UDP
    • Standard: ISO/IEC 13818-1 Systems
    • TS Packet Length: 188 bytes
    • Sync Byte: 0x47
    • Bit Rate: Constant
    • # of TS Supported: 24 SPTS
    • CODEC: MPEG-2
    • Output Resolution: 480i (30 FPS)
    • Audio: Pass-through
    • Routing Protocol: Unicast

      General Specifications

    • Dimensions: 19.0 x 19.2 x 1.75″ (483 x 488 x 45 mm)
    • Unit Weight: 9.5 lbs. (4.31 kg)
    • Shipping Weight: 12 lbs. (5.44 kg)
    • Power: 110/230 VAC, 0.9/0.45 A, 60/50 Hz
    • Power Consumption: 60 W
    • Operating Temperature: 32 to 122 °F (0 to 50 °C)
    • Storage Temperature: -13 to 158 °F (-25 to 70 °C)
    • Operating/Storage: 0 to 95% RH @ 35 °C max,
    • Humidity: non-condensation
