Blonder Tongue Clearview 4:2 24 Program HD 1080 Transcoder with Audio Passthrough & COM3000

Add to Wishlist
  • H.264 to MPEG-2 Transcodes up to 24 HD or SD programs
  • Full 1080p HD support, IP input to IP output
  • Compatible with Technicolor’s COM3000 DirecTV receivers
  • Compatible with BT Labs’ NXG to support on-site bulk transcoding applications

د.إ39,099.00

Add to Wishlist

The Clearview 4:2 can Transcode up to twenty-four (24) HD or SD programs from H.264 (MPEG-4) to MPEG-2 in 1RU. The unit accepts Unicast H.264 IP transport streams and re-encodes the video content to SD MPEG-2 transport streams for IP Unicast delivery.

The Clearview 4:2 can be configured to receive up to twenty-four (24) H.264 AES-128 encrypted IP channels from Technicolor COM3000/2000 satellite receivers. The Clearview 4:2 decrypts the AES-128 content and Transcodes the decrypted H.264 content into MPEG-2, while preserving the DirecTV `forensic watermarking’ and returns the content to the Technicolor COM3000/2000 devices.

  • Features:

    • H.264 to MPEG-2 Transcodes up to 24 HD or SD programs
    • Full 1080p HD support, IP input to IP output
    • Compatible with Technicolor’s COM3000 DirecTV receivers
    • Compatible with BT Labs’ NXG to support on-site bulk transcoding applications
SKU: BT-CLEARV-42 Category: Tag:

  • Specifications:

    • Input
    • Connectors: 1x Bi-directional Front Panel RJ45 (IP Video Port, Input/Output), 1x Bi-directional Front Panel RJ45 (Control
      Interface)
    • Standard Protocols Supported: UDP
    • Standard: ISO/IEC 13818-1 Systems
    • TS Packet Length: 188 bytes
    • Sync Byte: 0x47
    • TS Supported: 24 SPTS
    • Video Format: MPEG-2, H.264 (AVC); H.265 (HEVC)
    • Video Resolution:
      480i (60 FPS);
      480p (30/60 FPS);
      720p (30/60 FPS);
      1080i (60 FPS);
      1080p (30 FPS);
    • Closed Captioning: EIA608/EIA708
    • Addressing: Unicast
    • Audio Input Formats: Dolby® AC3, AAC, MPEG1-Layer2 (Pass-through/Decode only), MP3
    • SAP: Supported
    • Audio Rates: 64, 96, 112, 128, 160, 192, 224, 256, 320, and 384 Kbps

      Alarms & Monitoring

    • Local Monitoring:
      1x Power LED
      1x Temperature LED
      24x Status LEDs
    • Local Control: 1x IP Reset Button
    • Remote Control: 1x RJ45 (1000Base-T GbE)

      Output

    • Connector: 1x Bi-directional Front Panel RJ45 (IP Video Port, Input/Output)
    • Standard: 1000Base-T (GbE)
    • Protocols Supported: UDP
    • Standard: ISO/IEC 13818-1 Systems
    • TS Packet Length: 188 bytes
    • Sync Byte: 0x47
    • Encoding Type: CBR/Capped VBR
    • Video Bit Rates: 2-19 Mbps (0.1 Mbps increments)
    • TS Supported: 24 SPTS
    • Video Format: MPEG-2, H.264 (AVC); H.265 (HEVC)
    • Video Resolution:
      480i (60 FPS);
      480p (30/60 FPS);
      720p (30/60 FPS);
      1080i (60 FPS);
      1080p (30 FPS)
    • Closed Captioning: EIA608/EIA708
    • Addressing: Unicast, Multicast
    • Audio Output Formats: Dolby® AC3, AAC, MP3 (MPEG1-Layer2 Pass-through only)
    • SAP: Supported
    • Audio Bit Rates: 128, 192, and 256 Kbps

      General Specifications

    • Dimensions: 19.0 x 19.2 x 1.75″ (483 x 488 x 45 mm)
    • Unit Weight: 9.5 lbs. (4.31 kg)
    • Shipping Weight: 12 lbs. (5.44 kg)
    • Power: 110/230 VAC, 0.9/0.45 A, 60/50 Hz
    • Power Consumption: 64 W
    • Operating Temperature: 32 to 122 °F (0 to 50 °C)
    • Storage Temperature: -13 to 158 °F (-25 to 70 °C)
    • Operating/Storage: 0 to 95% RH @ 35 °C max,
    • Humidity: non-condensation
