Blustream SC12SP-V2 HDMI 18G Splitter/Down-Scaler w/Audio De-Embed

Add to Wishlist
  • Features 1 x HDMI input that is replicated to 2 x HDMI outputs
  • Supports HDMI 2.0 18 Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4
  • HDMI output 2 supports 4K UHD video pass-through

AED2,599.00

Add to Wishlist

The BlustreamĀ SC12SP-V2Ā is a 4K HDMI 2.0 splitter with in-built scaler, designed for installations in which a single 4K video source needs to be distributed to multiple displays that support different maximum video resolutions. The SC12SP-V2 supports downscaling of up to 4K @ 60Hz 4:4:4 video to various lower resolution video formats. The SC12SP-V2 also includes audio breakout, advanced EDID management and supports HDCP2.2

  • Features:

    • Features 1 x HDMI input that is replicated to 2 x HDMI outputs
    • Supports HDMI 2.0 18 Gbps specification including HDR
    • Supports up to 4K UHD 60Hz 4:4:4
    • HDMI output 2 supports 4K UHD video pass-through
    • HDMI output 1 will down-scale the video input to the following formats:
    • – 1080P@ 24/25/30/50/60Hz (for screens that do not support 4K)
    • – 4K 50/60Hz 4:2:0 (for screens that do not support full 4K @ 60Hz 4:4:4)
    • Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD
    • Master Audio transmission
    • HDMI audio breakout to analog L/R audio and coaxial digital outputs concurrently
    • Advanced EDID management
    • HDCP2.2 support
SKU: SC12SP-V2 Category: Tag:

  • Specifications:

    • Video Input Connectors:Ā 1 x HDMI Type A, 19-pin, female
    • Video Output Connectors:Ā 2 x HDMI Type A, 19-pin, female
    • Audio Output Connectors:Ā 1 x RCA (S/PDIF), 1 x 3.5mm stereo jack (L/R)
    • EDID:Ā 4-PIN DIP switch
    • Product upgrade:Ā 1 x 3-Pin Phoenix connector & 1 x Type A USB female
    • Dimensions (W x H x D):Ā 122mm x 23mm x 135mm
    • Shipping Weight:Ā 0.8kg
    • Operating Temperature:Ā 32Ā°F to 104Ā°F (0Ā°C to 40Ā°C)
    • Storage Temperature:Ā -4Ā°F to 140Ā°F (-20Ā°C to 60Ā°C)
    • Power Supply:Ā 5V/1A DC

  • Item Includes:

    • 1xĀ SC12SP-V2
    • 1xĀ 5V/1A DC power supply
    • 1xĀ Mounting kit
    • 1xĀ Quick Reference Guide
