Brocade VDX 6740 – switch – 24 ports – managed – rack-mountable

Add to Wishlist

Quick tech specs

  • Switch
  • managed
  • front to back airflow
  • L3
  • 24 x SFP+
  • desktop, rack-mountable

123,499.00 د.إ

Add to Wishlist

Know your gear

Brocade VDX 6740 switch provides the advanced feature set that data centers require and deliver the high performance and low latency virtualized environments demand. Together with Brocade VCS Fabric technology, the switch can simplify network design and operations for a more automated and efficient network, offers the flexibility needed to easily scale networks, delivers the intelligence to more effectively manage Virtual Machine (VM) mobility and rack density, as well as provides a cloud-ready infrastructure.
SKU: BR-VDX6740-24-F Category: Tag:
Overview
Brand Brocade
Product Line Brocade VDX
Model 6740
Manufacturer EXTREME NETWORKS
Network & Communication
Advanced Switching Layer 3
Compliant Standards IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3x, IEEE 802.3z
Features 24 MB packet buffer, Access Control List (ACL) support, ARP support, Automatic Migration of Port Profiles (AMPP), Class of Service (CoS), Data Center Bridging (DCB), Data Center Bridging Exchange (DCBX) support, Deficit Weighted Round Robin (DWRR), DHCP support, Enhanced transmission selection, Equal-Cost Multipath (ECMP), Firmware upgradable, Flow control, High Availability, IGMP snooping, IPv4 support, IPv6 support, ISL support, Layer 2 load balancing, Layer 3 load balancing, Management Information Base (MIB), Multiple Spanning Tree Protocol (MSTP) support, NTP time synchronization, Per-VLAN Spanning Tree Plus (PVST+), Priority-based flow control, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Role based access control, sFlow, Spanning Tree Protocol (STP) support, STP PortFast, STP Root Guard, Strict Priority (SP), Tagged VLAN, Trivial File Transfer Protocol (TFTP) support, Uni-Directional Link Detection (UDLD), Virtual Routing and Forwarding (VRF), VLAN support
Form Factor (Hubs & Switches) Desktop, Rack-mountable
Jumbo Frame Support 9216 bytes
MAC Address Table Size 160,000 entries
Manageable Yes
Max Units in a Stack 32
Ports 24
Product Type Switch
Remote Management CLI, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, Telnet
Routing Protocol BGP, BGP-4, IGMP, IGMPv2, OSPF, PIM-SM, Static IP routing, VRRP, VRRPE
Stackable Yes
Subcategory Network hubs and switches
Switching Type 10 Gigabit Ethernet
Connectivity
Interface Provided 1 x 1000Base-T RJ-45 management, 1 x console RJ-45 management, 1 x USB Type A management, 4 x QSFP+ (breakout compatible), 48 x SFP+
Port Quantity 24
Port Type SFP+
Power
Frequency 50/60 hertz
Hot-Plug Yes
Power Consumption Operational 110 watt
Power Provided 250 watt
Power Supplies Installed 2
Power Supplies Supported 2
Redundant Power Supply Yes
Redundant Power Supply Supported 1+1
Software
Software Type Brocade ISL Trunking, Brocade Network OS
Technical Information
Encryption MD5
Humidity Range Storage 10 – 90% (non-condensing)
Max Operating Temperature 104°F
Max Storage Temperature 158°F
Min Operating Temperature 32°F
Min Storage Temperature -13°F
Operating Humidity 10 – 85% (non-condensing)
Product Information
Airflow Direction Front to back airflow
Authentication Method LDAP, RADIUS, Secure Shell v.2 (SSH2), TACACS+
Capacity ACL entries: 13,000, ARP entries: 32,000, IPv4 routes: 12,000, IPv6 routes: 3,000, Port profiles: 1,024, Virtual interfaces (VLANs): 4,096
Device Type Internal power supply
Packaged Quantity 1
Performance Forwarding performance: 960 Mbps, Port-to-port latency: 850 ns, Switching fabric bandwidth: 1.28 Tbps
Included Items
Cables 1 x serial cable
Included Accessories 2 GB USB flash drive, Rubber feet
Dimensions & Weight
Height 1.7 inch
Height (Rack Units) 1
Weight 19.09 lbs
Width 17.3 inch
Depth 16.1 inch
Certifications & Listings
Compliant Standards ANSI C63.4, BSMI, CAN/CSA C22.2 No. 60950-1-07, CCC, CISPR 22, CNS 14336(94), CSA C22.2 No. 60950-1 Second Edition, C-Tick, EN 60950-1 Second Edition, EN55022 Class A, EN55024, FCC Class A certified, GB 17625.1-2003 EMC, GB 4943, GB 9254-2008, GOST, GOST-R 51318.22-99, GOST-R 51318.24-99, ICES-003 Class A, IEC 60950-1 Second Edition, JEIDA, KCC Class A, KN22, KN24, RoHS 6/6, UL 60950-1-07, VCCI Class A
