BZBGEAR 12G/6G/3G/HD-SDI to HDMI 2.0 Converter with Audio Extraction

Add to Wishlist
Key Features
  • 1 x 12G/6G/3G/HD-SDI Input, HDMI 2.0 Out
  • 1 x 12G/6G/3G/HD-SDI Loop Output
  • Supports up to UHD 4K60 Resolution I/O
  • Extract Audio from 3.5mm Output
  • Lossless Signal Conversion
  • Compact, Rugged Metal Enclosure
  • Power and Signal Status LEDs

AED6,499.00

Add to Wishlist

Expand your video output and display possibilities with the 12G/6G/3G/HD-SDI to HDMI 2.0 Converter with Audio Extraction from BZBGear. The converter enables you to link SDI devices, such as cameras or computers to pro-style HDMI monitors or recorders. It features one 12G/6G/3G/HD-SDI input, one 12G/6G/3G/HD-SDI loop output, and one HDMI 2.0 output. It supports input and output signals up to UHD 4K60 with RGB or YCC 4:2:2 deep color.

The converter allows you to extract analog audio from your transmission using the 3.5mm audio output jack. It also ensures lossless transmission over longer distances. Its rugged metal enclosure features built-in mounting ears for mounting the compact device on your console, wall, or rig.

Clear Images
Maintain stunning image quality up to UHD 4K60
Audio
The converter supports 7.1- or 5.1-channel surround audio and you can extract audio via a 3.5mm stereo mini output
HDMI Output & SDI Loop Output
The device features an HDMI output and a SDI loop output to view content locally
Status LEDs
See signal and power status at a glance with built-in status lights
Durable Metal Enclosure
Designed with a metal chassis for years of reliable use
SKU: BG-4KSH Category: Tag:
Inputs / Outputs
Video Inputs
1x BNC (12G-SDI) Female
Audio Inputs
No
Video Outputs
1x BNC (12G-SDI) Female (Loop Output)
1x HDMI (2.0) Female
Audio Outputs
1x 1/8″ / 3.5 mm TRS Analog Female
Expansion Slots
No
Format Support
Input Video Format
SDI (4:2:2 YCC)
UHD 4K at 23.98/24/25/29.97/30/50/59.94/60 fps
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
480i / 525 lines at 59.94 fps
576i / 625 lines at 50 fps
Output Video Format
HDMI (4:2:2 YCC)
UHD 4K at 23.98/24/25/29.97/30/50/59.94/60 fps
DCI 2K at 23.98/24/25/29.97/30/50/59.94/60 fps
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF at 25/29.97/30 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
480i / 525 lines at 59.94 fps
576i / 625 lines at 50 fps
Embedded Audio
HDMI/SDI
Standards
Video Standard Compliance
SMPTE 259M/274M/292M/296M/424M/ST-2081/ST-2082
HDR Support
Not Specified by Manufacturer
Power
Power I/O
1x Micro-USB (5 VDC at 1 A) Input
Power Consumption
Device: 2.5 W
Environmental
Operating Temperature
32 to 72°F / 0 to 40°C
Operating Humidity
20 to 90% ()
General
Certifications
CE, FCC, RoHS
Dimensions
3.6 x 1.8 x 0.9″ / 92 x 45 x 23 mm
Weight
6.2 oz / 175 g
Packaging Info
Package Weight
0.615 lb
Box Dimensions (LxWxH)
8.5 x 5.6 x 2.8″
