Cisco 1941 – wireless router – 802.11a/b/g/n (draft 2.0) – desktop, rack-mountable


Tech overview

Cisco 1941 – Wireless router – GigE – 802.11a/b/g/n (draft 2.0) – rack-mountable

8,199.00 د.إ

The platforms are architected to enable the next phase of branch-office evolution, providing rich media collaboration and virtualization to the branch while maximizing operational cost savings The Integrated Services Routers Generation 2 platforms are future-enabled with multicore CPUs, Gigabit Ethernet switching with enhanced POE, and energy monitoring and control capabilities while enhancing overall system performance. Overall, the Cisco 1900 series offer unparalleled total cost of ownership savings and network agility through the intelligent integration of market leading security, unified communications, wireless, and application services.

This Cisco 1900 series integrated services router offers embedded hardware encryption acceleration, optional firewall, intrusion prevention, and application services. In addition, the platforms support the industries widest range of wired and wireless connectivity options such as T1/E1, xDSL, 3G, and GE.

SKU: CISCO1941W-A/K9 Category: Tag:
Specifications
General
Device Type Wireless router
Enclosure Type Desktop, rack-mountable – modular – 2U
Connectivity Technology Wireless, wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet,
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g,
IEEE 802.11n (draft 2.0)
Network / Transport Protocol IPSec, PPPoE, L2TPv3
Routing Protocol OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM,
IGMPv3, GRE, PIM-SSM, static IPv4 routing,
static IPv6 routing, policy-based routing
(PBR), MPLS, Bidirectional Forwarding
Detection (BFD), IPv4-to-IPv6 Multicast
Remote Management Protocol SNMP, RMON
Encryption Algorithm LEAP, MD5, TLS, PEAP, TKIP, WPA, WPA2
Authentication Method RADIUS, Extensible Authentication Protocol
(EAP), EAP-FAST
Features
Firewall protection Yes
Hardware encryption Yes
VPN support Yes
MPLS support Yes
Syslog support Yes
IPv6 support Yes
CBWFQ Yes
WRED Yes
Compliant Standards
IEEE 802.11b Yes
IEEE 802.11a Yes
IEEE 802.11g Yes
IEEE 802.3ah Yes
IEEE 802.1ah Yes
IEEE 802.1ag Yes
IEEE 802.11n (draft 2.0) Yes
CISPR 22 Class A Yes
CISPR 24 Yes
EN55024 Yes
EN55022 Class A Yes
EN50082-1 Yes
CAN/CSA-E60065-00 Yes
ICES-003 Class A Yes
CS-03 Yes
AS/NZS 3548 Yes
FCC CFR47 Part 15 Yes
UL 60950-1 Yes
IEC 60950-1 Yes
EN 60950-1 Yes
CSA C22.2 No. 60065 Yes
BSMI CNS 13438 Yes
EN 300 386 Yes
RAM
Installed 512 MB
Max 2 GB
Flash Memory
Installed 256 MB
Max 8 GB
Status Indicators
Power Yes
Link/activity Yes
Expansion / Connectivity
Interfaces
10/100/1000Base-T 2 x RJ-45
Management 1 x console – RJ-45
Management 1 x console – mini-USB Type B
Serial 1 x auxiliary – RJ-45
USB 2 x 4 pin USB Type A
Expansion Slots
EHWIC 2 (total) / 2 (free)
CompactFlash 2 (total) / 1 (free)
Antenna
Type External detachable
Qty 3
Directivity Omni-directional
Gain Level 2 dBi
Power
Power Device Internal power supply
Voltage Required AC 120/230 V (50/60 Hz)
Miscellaneous
Rack Mounting Kit Included
Software / System Requirements
OS Provided Cisco IOS IP Base
Dimensions & Weight
Width 13.5 in
Depth 11.5 in
Height 3.5 in
Weight 12.79 lbs
