General |
Device Type | Expansion module – 2 ports |
Form Factor | Plug-in module |
Networking |
Connectivity Technology | Wired |
Data Link Protocol | 10 Gigabit Ethernet |
Features | Flow control, full duplex capability, MPLS support, Quality of Service (QoS), NetFlow |
Compliant Standards | IEEE 802.1x, IEEE 802.3ah, IEEE 802.1ag, ITU-T G.709 |
Expansion / Connectivity |
Interfaces | 2 x network – XFP |
Compatible Slots | 1 x expansion slot |
Miscellaneous |
Compliant Standards | NEBS level 3, FCC Class A certified, ETSI, CISPR 22 Class A, EN 61000-3-2, EN55022, VCCI Class A ITE, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, AS/NZ 3548 Class A, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825, FDA, CSA C22.2 No. 60950-1, BSMI Class A |
Dimensions & Weight |
Width | 1.7 in |
Depth | 20.5 in |
Height | 14 in |
Weight | 14 lbs |
Environmental Parameters |
Min Operating Temperature | 41 °F |
Max Operating Temperature | 104 °F |
Humidity Range Operating | 10 – 85% |
Compatibility Information |
Designed For | Cisco ASR 9006, 9006 Chassis, 9006 DC Chasis V2, 9006 with PEM Version 2, 9010, 9010 for High Scale, 9010 with PEM Version 2, 9904, 9910, 9910 Chassis, 9912, 9912 DC Chassis V2, 9912 TH, 9922, 9922 Chassis with PEM Version 2 |
