General |
|
Device Type |
Router |
Enclosure Type |
Rack-mountable, wall-mountable – modular – 1U |
Connectivity Technology |
Wired |
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
Capacity |
Cisco Unified SRST sessions: 35 ¦ Cisco Unified Communications Manager Express sessions: 35 |
Network / Transport Protocol |
IPSec, PPPoE, L2TPv3 |
Routing Protocol |
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), IPv4-to-IPv6 Multicast |
Remote Management Protocol |
SNMP, RMON, TR-069 |
Encryption Algorithm |
SSL |
Features |
Firewall protection, hardware encryption, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN), Web Services Management Agent (WSMA), NetFlow |
Compliant Standards |
IEEE 802.3, IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824, CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, BSMI CNS 13438, AS/NZS 3548 Class A, VCCI V-3, EN 61000, EN 300 386, CAN/CSA-C22.2 No. 60950-1 |
RAM |
512 MB (installed) / 2 GB (max) – DDR2 SDRAM |
Flash Memory |
256 MB (installed) / 8 GB (max) |
Status Indicators |
Power, link/activity |
Communications |
|
Type |
Voice / fax module |
Digital Ports Qty |
16 |
IP Telephony |
|
Voice Codecs |
G.711, G.722, G.723.1, G.728, G.729, G.729a, G.729ab, G.726 |
Expansion / Connectivity |
|
Interfaces |
2 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ Management: 1 x console – RJ-45 ¦ Management: 1 x console – mini-USB Type B ¦ Serial: 1 x auxiliary – RJ-45 ¦ USB: 2 x 4 pin USB Type A |
Expansion Slots |
4 (total) / 4 (free) x EHWIC ¦ 2 (total) / 1 (free) x PVDM ¦ 2 (total) / 1 (free) x CompactFlash ¦ 1 (total) / 1 (free) x ISM |
Power |
|
Power Device |
Internal power supply |
Voltage Required |
AC 120/230 V (50/60 Hz) |
Miscellaneous |
|
Pricing Type |
Refurbished |
Software / System Requirements |
|
OS Provided |
Cisco IOS Universal |
Software Included |
Cisco IOS IP Base, Cisco IOS Unified Communications, Cisco IOS Security |
Dimensions & Weight |
|
Width |
17.2 in |
Depth |
17.3 in |
Height |
1.8 in |
Weight |
13.45 lbs |
