| General |
|
| Device Type |
Router – 4-port switch (integrated) |
| Enclosure Type |
Desktop |
| Connectivity Technology |
Wired |
| Data Link Protocol |
Ethernet, Fast Ethernet |
| Capacity |
IPSec VPN tunnels: 20 |
| Network / Transport Protocol |
L2TP, RSVP, IPSec, FTP, DHCP, DNS, L2TPv3, DDNS, RTP |
| Routing Protocol |
OSPF, RIP-1, RIP-2, BGP, EIGRP, HSRP, NHRP, IGMPv3, GRE, policy-based routing (PBR), WCCP, Bidirectional Forwarding Detection (BFD) |
| Remote Management Protocol |
Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Encryption Algorithm |
DES, Triple DES, SSL, PKI, 128-bit AES, 192-bit AES, 256-bit AES |
| Authentication Method |
RADIUS, TACACS+ |
| Features |
NAT support, auto-uplink (auto MDI/MDI-X), content filtering, DiffServ support, manageable, MAC address filtering, IPv6 support, Intrusion Prevention System (IPS), firmware upgradable, Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Fair Queuing (WFQ), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Link Fragmentation and Interleaving (LFI), Dynamic Multipoint VPN (DMVPN), DHCP server, DNS proxy, IPv4 support, DHCP relay, Port Security, DHCP client, Management Information Base (MIB), Virtual Routing and Forwarding (VRF), 802.1x authentication, WWAN support, DiffServ Code Point (DSCP) support, Storm Control, Internet Control Message Protocol (ICMP) |
| Compliant Standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, EN55022, ICES-003, CISPR 22, FCC CFR47 Part 15, UL 60950-1 Second Edition, VCCI V-3, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, CNS 13438, FCC CFR47 Part 22, FCC CFR47 Part 24, EN 300 386, CAN/CSA C22.2 No. 60950 Second Edition, EN61000-3-3, EN61000-3-2, EN 301 908-1, EN 301 908-2, EN 301 511, EN 301 908-13 |
| Processor |
Sierra Wireless / Qualcomm MC7430 / MDM9230 |
| RAM |
1 GB (installed) / 1 GB (max) |
| Flash Memory |
1 GB (installed) / 1 GB (max) |
| Status Indicators |
System, active, wireless |
| Communications |
|
| Type |
Wireless cellular modem |
| Cellular Protocol |
GSM, UMTS, TD-SCDMA, HSPA+, DC-HSPA+, FDD LTE, TDD LTE |
| Max Transfer Rate |
100 Mbps |
| Expansion / Connectivity |
|
| Interfaces |
WAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ LAN: 4 x 10Base-T/100Base-TX – RJ-45 ¦ Management: 1 x RJ-45 ¦ USB: 1 x mini-USB Type A |
| Expansion Slots |
2 (total) / 2 (free) x SIM |
| Antenna |
|
| Antenna |
External detachable |
| Antenna Qty |
2 |
| Power |
|
| Power Device |
External power adapter |
| Voltage Required |
AC 120/230 V |
| Power Consumption Operational |
25 Watt |
| Miscellaneous |
|
| MTBF |
508,000 hours |
| Localization |
Australia, China, Japan, South Korea, India, South East Asia |
| Dimensions & Weight |
|
| Width |
7.7 in |
| Depth |
7.2 in |
| Height |
1.7 in |
| Weight |
2.2 lbs |
