Switch type |
Managed |
Switch layer |
L2 |
Quality of Service (QoS) support |
Y |
ARP inspection |
Y |
MIB support |
Y |
Basic switching RJ-45 Ethernet ports quantity |
16 |
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
Installed SFP modules quantity |
2 |
Console port |
RJ-45 |
Networking standards |
IEEE 802.1D, IEEE 802.1ab, IEEE 802.1af, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
Full duplex |
Y |
Broadcast storm control |
Y |
Auto MDI/MDI-X |
Y |
Spanning tree protocol |
Y |
VLAN support |
Y |
Virtual LAN features |
Private VLAN |
Number of VLANs |
4094 |
MAC address table |
16000 entries |
Switching capacity |
36 Gbit/s |
Jumbo frames support |
Y |
DHCP features |
DHCP server, DHCP client |
Access Control List (ACL) |
Y |
IGMP snooping |
Y |
Security algorithms |
SNMP, SSH |
SSH/SSL support |
Y |
Multicast support |
Y |
Management protocols |
SNMPv3, Telnet, RMON |
Rack mounting |
Y |
Form factor |
1U |
Product colour |
Grey |
LED indicators |
Activity, Link, PoE, Speed, System |
Safety |
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1 |
Electromagnetic compatibility |
47CFR Part 15 (CFR 47) Class A, AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2, EN61000-3-3, KN22 Class A, CNS13438 Class A |
Built-in processor |
Y |
Processor frequency |
800 MHz |
Internal memory |
512 MB |
Flash memory |
256 MB |
Mean time between failures (MTBF) |
2416689 h |
Harmonized System (HS) code |
85176990 |
AC input voltage |
110 – 240 V |
AC input frequency |
50 – 60 Hz |
Input current |
0.26 A |
Power consumption (typical) |
19.3 W |
Operating temperature (T-T) |
-5 – 40 °C |
Storage temperature (T-T) |
-25 – 70 °C |
Operating relative humidity (H-H) |
5 – 90% |
Storage relative humidity (H-H) |
5 – 95% |
Operating altitude |
0 – 3000 m |
Non-operating altitude |
0 – 4500 m |
Width |
268 mm |
Depth |
215 mm |
Height |
44 mm |
