Cisco Catalyst 6800 Series 10 Gigabit Ethernet Fiber Module with dual DFC4 – expansion module – 10 Gigabit SFP+ x 32

Add to Wishlist

Cisco Catalyst 6800 Series 10 Gigabit Ethernet Fiber Module with dual DFC4 – Expansion module – 10 Gigabit SFP+ x 32 – for Catalyst 6832-X Chassis (Standard Tables)

AED214,099.00

Add to Wishlist

The C6800 family 32-port 10-Gigabit Ethernet Fiber Module is suitable for deployment in all campus aggregation and core networks. The module supports hardware-based multicast replication, quality of service (QoS), access control lists (ACLs), jumbo frames, and low latency to enable secure and predictable performance for bandwidth-intensive applications. It’s designed to meet the increasing demand for aggregation of 10-Gigabit Ethernet streams in campus deployments, as well as for high-density 10-Gigabit Ethernet transport in the core.

SKU: C6800-32P10G= 1 Category: Tag:
Device Type Expansion module
Form Factor Plug-in module
Networking
Ports 10 Gigabit SFP+ x 32
Connectivity Technology Wired
Performance
Switching fabric bandwidth 80 Gbps
Forwarding performance 120 Mpps
Capacity
Multicast entries (IPv4) 64000
Multicast entries (IPv6) 64000
IPv4 forwarding table entries 256000
IPv6 forwarding table entries 128000
NetFlow entries 1000000
ACL entries 64000
MAC Address Table Size 128K entries
Remote Management Protocol RMON, SMON
Status Indicators Status, link/activity
Features MPLS support, IGMP snooping, LLQ, CBWFQ, WRED, ACL support, QoS, Jumbo Frames support, MLD snooping, DWRR, SRR, NetFlow, CoS, DSCP support, VPLS
Compliant Standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3ak, IEEE 802.1ae, IEEE 802.3an, IEEE 802.3aq
Processor / Memory RAM: 2 GB
Expansion / Connectivity
Interfaces 32 – SFP+
Miscellaneous Encryption Algorithm: 128-bit AES
Compliant Standards CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 A, IEC 60825-1, EN 60825-1, GR-1089-CORE, CAN/CSA C22.2 No. 60950, VCCI Class A, CNS 13438(95) Class A, GR-63-CORE, KN22 Class A, ETS 300 386, AS/NZS CISPR 22, ETSI 300 019, 21 CFR 1040.10, EN 55022 Class A
Power Power Consumption Operational: 587.6 Watt
Dimensions & Weight Width: 15.4 in
Depth: 16.4 in
Height: 1.7 in
Weight: 14.33 lbs
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range Operating 10 – 90% (non-condensing)
Compatibility Information Designed For: Cisco Catalyst 6832-X Chassis (Standard Tables)
