Enclosure Type |
Rack-mountable |
Subtype |
Gigabit Ethernet |
Ports |
24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ (uplink) |
Power Over Ethernet (PoE) |
PoE+ |
PoE Budget |
370 W |
Performance |
Stacking bandwidth: 80 Gbps<br>Switching capacity: 128 Gbps<br>Switching capacity with stacking: 208 Gbps<br>Forwarding rate: 95.23 Mpps |
Capacity |
Virtual networks: 1<br>IPv4 routes: 11000<br>IPv4 routing table entries: 3000<br>IPv6 routing table entries: 1500<br>Multicast scale: 1000<br>ACL scale entries: 1500<br>FNF entries: 16000<br>VLANs supported: 1024<br>Switched virtual interfaces (SVIs): 512<br>QoS hardware queues per port: 8<br>Packet buffer size: 6 MB |
MAC Address Table Size |
16000 entries |
Jumbo Frame Support |
9198 bytes |
Routing Protocol |
OSPF, RIP, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP |
Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, IPv4, IPv6, YANG |
Encryption Algorithm |
128-bit AES |
Features |
Access Control List (ACL) support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, Energy Efficient Ethernet, Class of Service (CoS), Flexible NetFlow (FNF), 802.1x authentication, DiffServ Code Point (DSCP) support, MACsec support, Control plane protection (CoPP), Blue Beacon LED, Zero-touch provisioning (ZTP), secure boot, Protocol Independent Multicast (PIM), First Hop Security (FHS), PVLAN support, Committed Information Rate (CIR), Cisco StackWise-80 technology, Cisco Trust Anchor module, Cisco Unified Access Data Plane (UADP) 2.0 |
Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3bz |
RAM |
2 GB |
Flash Memory |
4 GB |
Expansion / Connectivity |
Interfaces: 24 x 1000Base-T RJ-45 PoE+ – 30 W<br>4 x 10GBase-X SFP+ uplink<br>1 x network stack device<br>1 x management (LAN) RJ-45<br>1 x console RJ-45 |
Power |
Power Device: Internal power supply – hot-plug<br>Max Supported Qty: 2<br>Power Redundancy: Optional<br>Power Provided: 600 Watt<br>Voltage Required: AC 100-240 V (50 – 60 Hz) |
Miscellaneous |
MTBF: 390,310 hours<br>Compliant Standards: CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35 |
Software / System Requirements |
Software Included: Cisco Network Advantage (1 year) |
Dimensions & Weight |
Width: 17.5 in<br>Depth: 1.7 in<br>Height: 11.3 in<br>Weight: 10.38 lbs |
