| Switch type |
Managed |
| Switch layer |
L2 |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| Traffic classification |
Y |
| ARP inspection |
Y |
| Configuring Location Settings (CLI) |
Y |
| MIB support |
Y |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Installed SFP+ modules quantity |
4 |
| Console port |
RJ-45/Mini-USB |
| USB 2.0 ports quantity |
1 |
| Networking standards |
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u |
| 10G support |
Y |
| Full duplex |
Y |
| Link aggregation |
Y |
| Broadcast storm control |
Y |
| Auto MDI/MDI-X |
Y |
| Spanning tree protocol |
Y |
| Ethernet LAN data rates |
100,1000,10000 Mbit/s |
| VLAN support |
Y |
| Number of VLANs |
4094 |
| MAC address table |
16000 entries |
| Switching capacity |
128 Gbit/s |
| Forwarding rate |
41.67 Mpps |
| Static route |
Y |
| Number of static routes |
16 |
| Jumbo frames support |
Y |
| Jumbo frames |
10240 |
| DHCP features |
DHCP snooping |
| Access Control List (ACL) |
Y |
| IGMP snooping |
Y |
| IGMP entries |
1024 |
| SSH/SSL support |
Y |
| Loop protection |
Y |
| BPDU filtering/protection |
Y |
| Authentication |
Web-based authentication |
| Authentication type |
RADIUS |
| Multicast support |
Y |
| IPv4 multicast entries |
1024 |
| IPv6 multicast entries |
1024 |
| Product colour |
Grey |
| LED indicators |
Y |
| Certification |
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1 47CFR Part 15 (CFR 47) Class A, AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2, EN61000-3-3, KN22 Class A |
| Built-in processor |
Y |
| Processor model |
ARM7 |
| Processor frequency |
800 MHz |
| Memory type |
DRAM |
| Internal memory |
512 MB |
| Flash memory |
256 MB |
| Mean time between failures (MTBF) |
698220 h |
| Harmonized System (HS) code |
85176990 |
| AC input voltage |
110 – 220 V |
| AC input frequency |
50/60 Hz |
| Power over Ethernet (PoE) |
Y |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Power over Ethernet plus (PoE+) ports quantity |
24 |
| Total Power over Ethernet (PoE) budget |
370 W |
| Operating temperature (T-T) |
-5 – 50 °C |
| Storage temperature (T-T) |
-25 – 70 °C |
| Operating relative humidity (H-H) |
5 – 90% |
| Storage relative humidity (H-H) |
5 – 95% |
| Operating altitude |
0 – 3000 m |
| Non-operating altitude |
0 – 4500 m |
| Width |
444.5 mm |
| Depth |
345 mm |
| Height |
44 mm |
| Weight |
4.6 kg |
| Product family |
Catalyst |
