| Switch type |
Managed |
| Switch layer |
L3 |
| Quality of Service (QoS) support |
Y |
| ARP inspection |
Y |
| System event log |
Y |
| MIB support |
BRIDGE-MIB, CISCO-CDP-MIB, CISCO-CLUSTER-MIB, CISCO-CONFIG-MAN-MIB, CISCO-ENTITY-FRU-CONTROL-MIB, CISCO-ENVMON-MIB, CISCO-FLASH-MIB, CISCO-FTP-CLIENT-MIB, CISCO-HSRP-MIB, CISCO-HSRP-EXT-MIB, CISCO-IGMP-FILTER-MIB, CISCO-IMAGE-MIB, CISCO-IP-STAT-MIB, CISCO-L2L3-INTERFACE-CONFIG-MIB, CISCO-MAC-NOTIFI |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Basic switching RJ-45 Ethernet ports type |
Fast Ethernet (10/100) |
| SFP module slots quantity |
2 |
| Console port |
RJ-45 |
| Power connector |
AC-in jack |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Cable types supported |
Cat5e |
| Full duplex |
Y |
| IP routing |
Y |
| Link aggregation |
Y |
| Broadcast storm control |
Y |
| Rate limiting |
Y |
| Auto MDI/MDI-X |
Y |
| Spanning tree protocol |
Y |
| VLAN support |
Y |
| Number of VLANs |
1000 |
| MAC address table |
12000 entries |
| Jumbo frames support |
Y |
| Jumbo frames |
9016 |
| DHCP features |
DHCP server |
| Access Control List (ACL) |
Y |
| IGMP snooping |
Y |
| Security algorithms |
802.1x RADIUS |
| MAC address filtering |
Y |
| Static port security |
Y |
| SSH/SSL support |
Y |
| BPDU filtering/protection |
Y |
| IP-MAC-Port binding |
Y |
| Multicast support |
Y |
| Management protocols |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH |
| Switching protocols |
RIP-1, RIP-2, HSRP, static IP routing |
| Routing protocols |
HSRP, IP, RIP-1, RIP-2, RIPng |
| Rack mounting |
Y |
| Stackable |
N |
| Form factor |
1U |
| Product colour |
Black |
| LED indicators |
Y |
| Certification |
FCC, EN 55022B, VCCI, AS/NZS 3548, KCC, CE, GOST |
| Flash memory |
32 MB |
| Noise level |
41 dB |
| Mean time between failures (MTBF) |
377260 h |
| Sustainability certificates |
ENERGY STAR |
| Redundant power supply (RPS) support |
Y |
| Number of power supply units |
1 |
| AC input voltage |
120 – 230 V |
| AC input frequency |
50/60 Hz |
| Input current |
0.3 – 0.5 A |
| Power consumption (typical) |
24 W |
| Power over Ethernet (PoE) |
N |
| Operating temperature (T-T) |
0 – 45 °C |
| Storage temperature (T-T) |
-25 – 70 °C |
| Operating relative humidity (H-H) |
10 – 85% |
| Storage relative humidity (H-H) |
10 – 85% |
| Operating altitude |
0 – 3000 m |
| Non-operating altitude |
0 – 4573 m |
| Heat dissipation |
82 BTU/h |
| Width |
431.8 mm |
| Depth |
457.2 mm |
| Height |
25.4 mm |
| User guide |
Y |
| Manual |
Y |
| Product family |
Catalyst |
