Cisco Catalyst C3850-12XS-S Switch Layer 3 – 12 SFP/SFP+ – 1G/10G – IP Base – Wireless controller – managed- stackable
AED18,999.00
Cisco WS-C3850-12XS-S
WS-C3850-12XS-S switch provides 12 ports 10Gbps SFP+ connection with upgradeable IP base image and build in wireless controller provide fully convergence between wired and wireless on a single platform. It only supports 4 Ć 10 Gigabit Ethernet network module uplinks option.
Quick Specs
Figure 1 shows the appearance of the Cisco Catalyst WS-C3850-12XS-S.
Table 1 shows the Quick Specs.
| Product Code | WS-C3850-12XS-S |
| Enclosure Type | 1 RU |
| Feature Set | IP Base |
| Network SFP uplink module selection | C3850-NM-4-10G |
| Ports | 12 x 10/100/1000 10G SFP+ Optical ports |
| Maximum stacking number | 9 |
| Stack bandwidth | 480 Gbps |
| Forwarding Performance | 227.28Mpps |
| Switching Capacity | 320Gbps |
| RAM | 4 GB |
| Flash Memory | 4 GB |
| Dimensions | 44.5 cm x 45.0 cm x 4.45 cm |
Product Details
Figure 2 shows the front panel of the WS-C3850-12XS-S.
Noteļ¼
| ā | UID (blue beacon) | ā¤ | USB Type A storage port |
| ā” | Mode button | ā„ | 12 ports of 10G SFP+ |
| ā¢ | Status LEDs | ā¦ | Network SFP uplink module slot |
| ā£ | USB mini-Type B (console) port |
Ā· The switch supports one hot-swappable network module that provides uplink ports to connect to other devices. The switch should only be operated with either a network module or a blank module installed.
Figure 3 shows the back panel of the WS-C3850-12XS-S switch.
Noteļ¼
| ā | Ground connector | ā¤ | StackWise port connector |
| ā” | CONSOLE (RJ-45 console port) | ā„ | StackPower connector |
| ā¢ | Fan module | ā¦ | Power supply modules |
| ā£ | MGMT port |
Figure 4 shows the StackWise-480 and StackPower connectors.
IP base feature set can only stack with other Catalyst 3850 Series IP base switches. Power stack capacity is supported by Cisco Stackpower technology to provide power redundancy among stacking members.
The Modules, Licenses and Accessories
Table 2 shows some recommended modules, licenses and accessories of this switch.
| Models | Description |
| C3850-NM-4-10G | Cisco 3850 Series 4 x 10GE Network Module |
| L-C3850-12-S-E | C3850-12 IP Base to IP Services Electronic RTU License |
| PWR-C1-350WAC | Cisco 3850 Series Power Supply 350W AC |
| PWR-C1-350WAC/2 | Cisco 3850 Series Secondary Power Supply 350W AC Config 1 Secondary Power Supply |
| STACK-T1-50CM= | Cisco StackWise-480 50cm stacking cable for Cisco Catalyst 3850 series switch |
| STACK-T1-1M= | Cisco StackWise-480 1m stacking cable for Cisco Catalyst 3850 series switch |
Compare to Similar Items
Table 3 shows the comparison between WS-C3850-12XS-S and WS-C3850-12S-S.
| Models | WS-C3850-12XS-S | WS-C3850-12S-S |
| Feature Set | IP Base | IP Base |
| Ports | 12 ports of 10G SFP+ Ethernet fiber
connection with Flexible Netflow feature |
12 ports of SFP Ethernet fiber
connection with Flexible Netflow feature |
| Network SFP uplink
module selection |
C3850-NM-4-10G | C3850-NM-4-1G
C3850-NM-2-10G |
| Weight | 5.8 kg |
|---|---|
| Dimensions | 17.7 × 17.5 × 1.75 cm |
Specification (WS-C3850-12XS-S)
| Cisco catalyst 3850-24S-S | ||
| model info: | WS-C3850-12XS-S | |
| enclosure type | Rack-mountable – 1U | |
| Ports | 12 x SFP+ ports | |
| Network management Interface | ā Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling ā Management console port: RJ-45-to-DB9 cable for PC connections |
|
| Available PoE Power | None | |
| Switching Capacity | 320Gbps | |
| Maximum stacking number | 9 | |
| Stack Bandwidth | 480Gbps | |
| Forwarding Performance | 227.28Mpps | |
| FNF entries | 48,000 flows | |
| Maximum VLANs IDs | 1,000 | |
| MAC Address Table Size | 32K | |
| CPU | Multicore CPU | |
| RAM | 4 G | |
| Flash Memory | 4 G | |
| Wireless | ||
| Number of AP per switch/stack | 50 | |
| Number of wireless clients per switch/stack | 2000 | |
| Total number of WLANs per switch | 64 | |
| Wireless bandwidth per switch | up to 20Gbps | |
| Supported Aironet AP series | 3600, 3500, 2600, 1600, 1260, 1140, 1040 | |
| Expansion / Connectivity | ||
| Console ports | USB (Type-B), Ethernet (RJ-45) | |
| Expansion Slot(s) | 1 network module slot and 1 power redundant slot | |
| Network Modules Selection | āC3850-NM-4-10G: 4 x 10G or 4 x 1G uplinks network moduleĀ | |
| Stacking cable | āSTACK-T1-50CM StackWise stacking cable with a 0.5 m length āSTACK-T1-1M StackWise stacking cable with a 1.0 m length āSTACK-T1-3M StackWise stacking cable with a 3.0 m length |
|
| Stack Power Cable (recommended) | āCAB-SPWR-30CM stack power cable with a 30CM length āCAB-SPWR-150CM stack power cable with a 150CM length |
|
| Power supply | PWR-C1-350WAC | |
| Power Device | Power supply – redundant – plug-in module | |
| Power Redundancy | optional | |
| Voltage range (Auto) | 100V-240V | |
| Power Consumption of standalone(in Watts) | 109.75 (Max) | |
| Miscellaneous | ||
| Width | 17.5 Inches (44.5 Cm) | |
| Depth | 17.7 Inches (45.0 Cm) | |
| Height | 1.75 Inches (4.45 Cm) | |
| Weight | 12.9 Pounds (5.8 Kg) | |
| Rack Mounting Kit | optional | |
| Ā MTBF in hours | 371,440 | |
| Compliant Standards | ā IEEE 802.1D Spanning Tree Protoco ā IEEE 802.1p CoS Prioritization ā IEEE 802.1Q VLAN ā IEEE 802.1s ā IEEE 802.1w ā IEEE 802.1X ā IEEE 802.1X-Rev āIEEE 802.11 ā IEEE 802.1ab (LLDP) ā IEEE 802.3ad ā IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports |
ā IEEE 802.3 10BASE-T ā IEEE 802.3u 100BASE-TX ā IEEE 802.3ab 1000BASE-T ā IEEE 802.3z 1000BASE-X ā RMON I and II standards ā SNMP v1, v2c, and v3 |
| System software / license | ||
| System software | IOS IP Base (Upgradable) | |
| EnergyWise license | ENERGY-MGMT, ENERGY-MGT-100-K9 | |
| Software license | āC3850-12-S-E: IP Base to IP Services RTU paper license āL-C3850-12-S-E: IP Base to IP Services RTU electronic license |
|
| Access Point Licenses | āL-LIC-CT3850-UPG: Primary upgrade license SKU for Cisco 3850 wireless controller (e-delivery) āL-LIC-CTIOS-1A: 1 access point adder license for Cisco IOS Software based wireless controller (e-delivery) āLIC-CT3850-UPG: Primary upgrade license SKU for Cisco 3850 wireless controller (paper license) āLIC-CTIOS-1A: 1 access point adder license for the Cisco IOS Software based wireless controller (paper license) |
|
| features | āRPS Support āĀ Jumbo Frames ā VLANS āVoice Vlan āVTPv2 āCDPv2 āLLDP ā 802.3ad LACP and PAgP ā PVST/PVST+ ā 802.1W/802.1S āPort Fast/Uplink FastĀ āDynamic Trunking Protocol (DTP) ā port CoS Trust and Override ā Trusted Boundary ā ACL Classification āingress Policing ā Auto QoS ā Per VLAN policies ā 802.1p queues ā Scheduling ā Priority Queuing ā Configure CoS Priority Queues āConfigure CoS Priority Queues ā Configure Queue Weights ā Configure Buffers and Thresholds āClass & Policy Maps ā Modify CoS and DSCP Mapping ā Weighted Tail Drop ā IGMPv1,v2,v3 and MLDv1, v2 ā DHCP server ā DSCP transparency ā HSRP, VRRP ā RIPv1, v2 EIGRP stub, PIM stub, OSPF stub ā IPV6 management | |
| Advanced Network security | ā Port security ā DHCP snooping āDynamic ARP inspection (DAI) ā IP source guard āThe Unicast Reverse Path Forwarding (uRPF) ā Bidirectional data support on a SPAN ā User authentication ā Private VLANĀ āRouter and VLAN ACLsĀ ā complete identity and security ā Multidomain authentication ā MAC address notification ā IGMP filtering ā Cisco security VLAN ACL ā Secure Shell (SSH) Protocol, Kerberos, and Simple Network Management Protocol Version 3 (SNMPv3) ā Port-based ACLs ā TrustSec SXP ā IEEE 802.1ae ā TACACS+ and RADIUS authentication ā Cisco standard and extended IP security router ACLs āĀ Bridge protocol data unit (BPDU) Guard ā Spanning Tree Root Guard (STRG) ā Wireless end-to-end securityĀ |
|
| Management | āBRIDGE-MIB āCISCO-AUTH-FRAMEWORK-MIB āCISCO-BGP4-MIB, BGP4-MIB āCISCO-BRIDGE-EXT-MIB āCISCO-BULK-FILE-MIB āCISCO-CABLE-DIAG-MIB āCISCO-CALLHOME-MIB āCISCO-CEF-MIB āCISCO-CIRCUIT-INTERFACE-MIB āCISCO-ENTITY-VENDORTYPE-OID-MIB āCISCO-CONTEXT-MAPPING-MIB āCISCO-DEVICE-LOCATION-MIB āCISCO-DHCP-SNOOPING-MIB āCISCO-EIGRP-MIB āCISCO-EMBEDDED-EVENT-MGR-MIB āCISCO-ENTITY-FRU-CONTROL-MIB āCISCO-ENTITY-SENSOR-MIB āENTITY-MIB āCISCO-ERR-DISABLE-MIB āCISCO-CONFIG-COPY-MIB āCISCO-FLOW-MONITOR-MIB āCISCO-FTP-CLIENT-MIB āCISCO-HSRP-EXT-MIB āCISCO-HSRP-MIB āCISCO-IETF-ISIS-MIB āCISCO-IF-EXTENSION-MIB āCISCO-IGMP-FILTER-MIB āCISCO-CONFIG-MAN-MIB āCISCO-IP-CBR-METRICS-MIB āCISCO-IPMROUTE-MIB āCISCO-IP-STAT-MIB āCISCO-IP-URPF-MIB āCISCO-L2L3-INTERFACE-CONFIG-MIB āCISCO-LAG-MIB āCISCO-LICENSE-MGMT-MIB āCISCO-MAC-AUTH-BYPASS-MIB āCISCO-MAC-NOTIFICATION-MIB āCISCO-MDI-METRICS-MIB āCISCO-FLASH-MIB āCISCO-OSPF-MIB āCISCO-OSPF-TRAP-MIB āCISCO-PAE-MIB āCISCO-PAGP-MIB āCISCO-PIM-MIB āCISCO-PING-MIB āCISCO-PORT-QOS-MIB āCISCO-PORT-SECURITY-MIBāCISCO-PORT-STORM-CONTROL-MIB āCISCO-POWER-ETHERNET-EXT-MIB āCISCO-PRIVATE-VLAN-MIB āCISCO-PROCESS-MIB āCISCO-PRODUCTS-MIBāCISCO-RF-MIB āCISCO-RTP-METRICS-MIB āCISCO-RTTMON-MIB āCISCO-SMART-INSTALL-MIB |
āCISCO-SNMP-TARGET-EXT-MIB āCISCO-STACKMAKER-MIB āCISCO-MEMORY-POOL-MIB āCISCO-STP-EXTENSIONS-MIB āCISCO-SYSLOG-MIB āCISCO-TCP-MIB āCISCO-UDLDP-MIB āCISCO-VLAN-IFTABLE-RELATIONSHIP-MIB āCISCO-VLAN-MEMBERSHIP-MIB āCISCO-VTP-MIB āEtherLike-MIB āHC-RMON-MIB āIEEE8021-PAE-MIB āIEEE8023-LAG-MIB āIF-MIB āIGMP-MIB āIGMP-STD-MIB āIP-FORWARD-MIB āIP-MIB āIPMROUTE-STD-MIB āLLDP-EXT-MED-MIB āLLDP-MIB āNOTIFICATION-LOG-MIB āOLD-CISCO-MEMORY-MIB āCISCO-CDP-MIB āPOWER-ETHERNET-MIB āRMON2-MIB āRMON-MIB āSNMP-COMMUNITY-MIB āSNMP-FRAMEWORK-MIB āSNMP-MPD-MIB āSNMP-NOTIFICATION-MIB āSNMP-PROXY-MIB āSNMP-TARGET-MIB āSNMP-USM-MIB āSNMPv2-MIB āSNMP-VIEW-BASED-ACM-MIB āTCP-MIB āUDP-MIB āCISCO-IMAGE-MIB āCISCO-STACKWISE-MIB āAIRESPMACE-WIRELESS-MIB āCISCO-LWAPP-IDS-MIB āCISCO-LWAPP-AP-MIB āCISCO-LWAPP-CCX-RM-MIB āCISCO-LWAPP-CLIENT-ROAMING-MIB āCISCO-LWAPP-DOT11-CCX-CLIENT-DIAG-MIB āCISCO-LWAPP-DOT11-CCX-CLIENT-MIB āCISCO-LWAPP-DOT11-CLIENT-CCX-REPORTS-MIB āCISCO-LWAPP-DOT11-CLIENT-MIB āCISCO-LWAPP-DOT11-MIB āCISCO-LWAPP-DOWNLOAD-MIB āCISCO-LWAPP-LINKTEST-MIB āCISCO-LWAPP-MFP-MIB āCISCO-LWAPP-MOBILITY-EXT-MIB āCISCO-LWAPP-QOS-MIB āCISCO-LWAPP-REAP-MIB āCISCO-LWAPP-ROGUE-MIB āCISCO-LWAPP-RRM-MIB āCISCO-LWAPP-SI-MIB āCISCO-LWAPP-TSM-MIB āCISCO-LWAPP-WLAN-MIB āCISCO-LWAPP-WLAN-SECURITY-MIB |
| Technical Support and Services | ā Cisco SMARTnet Service ā Cisco Smart Foundation Service ā Cisco SP Base Service ā Cisco Focused Technical Support Services | |
| Environmental Ranges | ||
| Fahrenheit | Centigrade | |
| With AC power supply Operating environment and altitude |
||
| Operating temperature up to 5000 ft (1500 m) | 23ĀŗF to 113ĀŗF | Ā -5ĀŗC to +45ĀŗC |
| Operating temperature up to 10,000 ft (3000 m) | 23ĀŗF to 104ĀŗF | Ā -5ĀŗC to +40ĀŗC |
| Short-term exception at sealevel with single fan failure | 23ĀŗF to 113ĀŗF | -5ĀŗC to +45ĀŗC |
| Short-term exception up to 5000 feet (1500 m) | 23ĀŗF to 122ĀŗF | -5ĀŗC to 50ĀŗC |
| Short-term exception up to 10,000 feet (3000 m) | 23ĀŗF to 113ĀŗF | -5ĀŗC to 45ĀŗC |
| With DC power supply Operating environment and altitude (NEBS) |
||
| Operating temperature up to 6000 ft (1800 m) | 23ĀŗF to 113ĀŗF | Ā -5ĀŗC to +45ĀŗC |
| Operating temperature up to 10,000 ft (3000 m) | 23ĀŗF to 104ĀŗF | Ā -5ĀŗC to +40ĀŗC |
| Operating temperature up to 13,000 ft (4000m) | 23ĀŗF to 95ĀŗF | Ā -5ĀŗC to 35ĀŗC |
| Short-term exception up to 6,000 feet (1800 m) | 23ĀŗF to 131ĀŗF | Ā -5ĀŗC to +55ĀŗC |
| Short-term exception up to 10,000 feet (3000 m) | 23ĀŗF to 122ĀŗF | Ā -5ĀŗC to +50ĀŗC |
| Short-term exception up to 13,000 feet (4000 m) | 23ĀŗF to 113ĀŗF | Ā -5ĀŗC to +45ĀŗC |
| Short-term exception at sealevel with single fan failure | 23ĀŗF to 113ĀŗF | Ā -5ĀŗC to +45Āŗ |
| Storage environment | Ā -40ĀŗF to 160ĀŗF | Ā -40ĀŗC to 70ĀŗC |
| Feet | Meters | |
| Operating altitude | Up to 13,000 | Up to 4000m |
| Storage altitude | Up to 15,000 | Up to 4573m |
| Operating relative humidity | 10% to 95% noncondensing | |
| Storage relative humidity | 10% to 95% noncondensing |
