Cisco Integrated Services Router 4331 – Voice Security Bundle – router – rack-mountable
Tech overview
Cisco Integrated Services Router 4331 – Voice Security Bundle – router – GigE – WAN ports: 3 – rack-mountable – refurbished
21,899.00 د.إ
The Cisco 4000 family Integrated Services Router (ISR) revolutionizes WAN communications in the enterprise branch. With new levels of built-in intelligent network capabilities and convergence, it specifically addresses the growing need for application-aware networking in distributed enterprise sites. These locations tend to have lean IT resources. But they often also have a growing need for direct communication with both private data centers and public clouds across diverse links, including Multiprotocol Label Switching (MPLS) VPNs and the Internet.
| Specifications |
|---|
| General |
| Device Type | Router |
| Enclosure Type | Rack-mountable – modular – 1U |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Performance | Aggregate throughput: 100 Mbps |
| Network / Transport Protocol | IPSec, PPPoE, DHCP |
| Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), IPv4-to-IPv6 Multicast |
| Remote Management Protocol | SNMP, RMON |
| Features | Firewall protection, VPN support, VLAN support, Syslog support, IPv6 support, CBWFQ, WRED, wall mountable, IPSec VPN, ACL support, QoS, DMVPN, RADIUS support, NetFlow, IPFIX |
| Compliant Standards | IEEE 802.3, IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824, CISPR 22 Class A, CISPR 24, EN55024, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 3548 Class A, GB 4943, VCCI V-3, EN 61000, KN22, KN24, CNS 13438, EN 55022 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1 |
| RAM | 4 GB (installed) / 16 GB (max) – DDR3 SDRAM |
| Flash Memory | 4 GB (installed) / 16 GB (max) |
| Expansion / Connectivity |
| Interfaces | WAN / LAN: 2 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ Serial: 1 x console – RJ-45 ¦ Management: 1 x console – mini-USB Type B ¦ Serial: 1 x auxiliary – RJ-45 ¦ USB 2.0: 1 x 4 pin USB Type A ¦ 2 x SFP (mini-GBIC) ¦ Management: 1 x RJ-45 |
| Expansion Slots | 2 (total) / 2 (free) x NIM ¦ 1 (total) / 0 (free) x ISC ¦ 1 (total) / 1 (free) x Enhanced Service Module (SM-X) ¦ 2 (total) / 0 (free) x DIMM 240-pin |
| Power |
| Power Device | Internal power supply – 250 Watt |
| Installed Qty | 1 (installed) / 1 (max) |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous |
| Included Accessories | 32-channel voice DSP module |
| Rack Mounting Kit | Included |
| Pricing Type | Refurbished |
| Software / System Requirements |
| OS Provided | Cisco IOS Security |
| Software Included | Cisco IOS IP Base, Cisco IOS Unified Communications, Cisco Unified Border Element Enterprise Edition (10 sessions) |
| Dimensions & Weight |
| Width | 17.2 in |
| Depth | 17.2 in |
| Height | 1.8 in |
| Weight | 11.02 lbs |
