Cisco Network Convergence System 5501 – router – rack-mountable
Tech overview
Cisco Network Convergence System 5501 – Router – 40 Gigabit LAN, 100 Gigabit Ethernet – rack-mountable
540,799.00 د.إ
The Network Convergence System 5500 series offers high density of routed 100-GE ports for high-scale WAN aggregation. The 5500 series is designed to efficiently scale between data centers and large enterprise, web, and service provider WAN and aggregation networks.
| Specifications | |
|---|---|
| General | |
| Device Type | Router |
| Enclosure Type | Rack-mountable – 1U |
| Connectivity Technology | Wired |
| Data Link Protocol | Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet |
| Performance | |
| Throughput | 800 Gbps |
| Capacity | FIB entries: up to 1000000 |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | IS-IS, BGP, HSRP, VRRP, OSPFv2, OSPFv3, ECMP, IS-ISv6, MPLS |
| Remote Management Protocol | SNMP, SNMP 3, SSH |
| Authentication Method | TACACS+ |
| Features | Layer 3 switching, RPL support, Access Control List (ACL) support, Bidirectional Forwarding Detection (BFD), LACP support, Link Aggregation Control Protocol (LACP), Management Information Base (MIB), static routing, Class of Service (CoS), DiffServ Code Point (DSCP) support, Label Distribution Protocol (LDP), iPXE, Ethernet over MPLS (EoMPLS) |
| Compliant Standards | IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1ad, CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1 Second Edition, RoHS 6/6, GB 4943, Directive 2004/108/EC, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2006/95/EC, GR-1089-CORE, VCCI Class A, GR-63-CORE, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, CAN/CSA C22.2 No. 60950-1 Second Edition, EN 300 386, KN 61000-4 |
| Processor | 1 x 2 GHz |
| Expansion / Connectivity | |
| Interfaces | 48 x 10Gb Ethernet – SFP/SFP+ ¦ 6 x 100Gb Ethernet – QSFP28/QSFP+ ¦ Console: 1 x RJ-45 ¦ Management: 2 x RJ-45 |
| Power | |
| Power Device | Internal power supply (not installed) – hot-plug |
| Power Redundancy | Optional |
| Installed Qty | 2 (max) |
| Miscellaneous | |
| Included Accessories | Accessory kit |
| Software / System Requirements | |
| OS Required | Cisco IOS XR 6.1.1 |
| Dimensions & Weight | |
| Width | 17.4 in |
| Depth | 21.7 in |
| Height | 1.7 in |
| Weight | 22.8 lbs |
