Switch type |
Managed |
Quality of Service (QoS) support |
Y |
Web-based management |
Y |
ARP inspection |
Y |
System event log |
Y |
MIB support |
SNMPv2-SMI, CISCO-SMI, SNMPv2-TM, SNMPv2-TC, IANA-ADDRESS-FAMILY-NUMBERS-MIB, IANAifType-MIB, IANAiprouteprotocol-MIB, HCNUM-TC, CISCO-TC, SNMPv2-MIB, SNMP-COMMUNITY-MIB, SNMP-FRAMEWORK-MIB, SNMP-NOTIFICATION-MIB, SNMP-TARGET-MIB, SNMP-USER-BASED-SM-MIB, SNMP-VIEW-BASED-ACM-MIB, CISCO-SNMP-VACM-EXT |
Basic switching RJ-45 Ethernet ports quantity |
48 |
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
SFP+ module slots quantity |
4 |
Console port |
RS-232 |
USB 2.0 ports quantity |
1 |
Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3z |
10G support |
Y |
IP routing |
Y |
Routing entries |
16000 |
Link aggregation |
Y |
Broadcast storm control |
Y |
Spanning tree protocol |
Y |
VLAN support |
Y |
Virtual LAN features |
Private VLAN, Tagged VLAN |
Number of VLANs |
4096 |
MAC address table |
128000 entries |
Switching capacity |
176 Gbit/s |
Throughput |
132 Mpps |
Number of queues |
8 |
Jumbo frames support |
Y |
Jumbo frames |
9216 |
Packet buffer memory |
9 MB |
DHCP features |
DHCP server |
Access Control List (ACL) |
Y |
Security algorithms |
802.1x RADIUS |
MAC address filtering |
Y |
SSH/SSL support |
Y |
Multicast support |
Y |
Number of multicast groups filtered |
8000 |
Management protocols |
SNMP v1/v2/v3, CLI, RMON, SSHv2, Telnet, AAA, RADIUS, TACACS+, SPAN, NTP, ERSPAN |
Rack mounting |
Y |
Form factor |
1U |
Product colour |
Grey |
LED indicators |
Y |
On/off switch |
Y |
Safety |
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1, GB4943 |
Electromagnetic compatibility |
47CFR Part 15 (CFR 47) Class A, AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2, EN61000-3-3, KN22 Class A, CNS13438 Class A, EN55024, CISPR24, EN300386, KN24 |
Power supply included |
Y |
Redundant power supply (RPS) support |
Y |
AC input voltage |
100 – 240 V |
AC input frequency |
50 – 60 Hz |
Power consumption (typical) |
120 W |
Operating temperature (T-T) |
0 – 40 °C |
Storage temperature (T-T) |
-40 – 70 °C |
Operating relative humidity (H-H) |
10 – 85% |
Storage relative humidity (H-H) |
5 – 95% |
Operating altitude |
0 – 3000 m |
Heat dissipation |
409 BTU/h |
Width |
439 mm |
Depth |
505 mm |
Height |
44 mm |
Weight |
9.3 kg |
Harmonized System (HS) code |
85176990 |
Product family |
Nexus |
