Cisco Nexus – Network line card – 16 port – 400 Gbps – QSFP-DD


Cisco Nexus – Network line card – 16 port – 400 Gbps – QSFP-DD – Support for ACI spine – Designed to work with the Cisco Nexus 9500 Series

296,399.00 د.إ

The Cisco network adapter is engineered to meet the demands of modern data centers and high-performance computing environments. With a packet buffer size of 160 MB and support for up to 2 million IPv4 longest prefix match (LPM) entries, it ensures efficient data flow and performance. The adapter features 16 ports of 400 Gb Ethernet QSFP-DD, offering high-density connectivity options. Compliance with a broad spectrum of standards, including AS/NZS, CISPR, EN, FCC, and RoHS, ensures the adapter meets rigorous safety and environmental requirements. Additionally, features such as MACsec and SRv6 support, along with cloud scale architecture and breakout capability, provide the security and flexibility needed for modern network operations. An impressive mean time between failures (MTBF) of 338,442 hours underscores the adapter’s reliability, making it a smart choice for critical network infrastructures seeking robust performance and connectivity.

SKU: N9K-X9716D-GX 1 Category: Tag:
General
Device Type Expansion module
Form Factor Plug-in module
Networking
Ports 400Gb Ethernet QSFP-DD x 16
Connectivity Technology Wired
Data Link Protocol 400 Gigabit Ethernet
Data Transfer Rate 400 Gbps
Performance
Maximum Throughput 12.8 Tbps
Bandwidth 4.3 bpps
Capacity
Packet Buffer Size 160 MB
LPM Entries (IPv4) 2,000,000
LPM Entries (IPv6) 1,000,000
Host Table Entries (IPv4) 2,000,000
Host Table Entries (IPv6) 32,000
MAC Address Entries 1,000,000
Multicast Routes 131,000
IGMP Groups 32,000
Virtual Interfaces (VLANs) 4,096
VRF Instances 16,000
Port Channels 512
Max Links in Port Channel 32
ECMP Paths 64
SPAN Sessions 32
MST Instances 64
RPVST Instances 4,000
HSRP Groups 490
VXLAN Tunnel Endpoints 10,000
Features MACsec support, breakout capability, cloud scale architecture, hot swappable, SRv6 support, port-side intake
Expansion / Connectivity
Interfaces 16 x 400Gb Ethernet – QSFP-DD
Miscellaneous
MTBF 338,442 hours
Compliant Standards CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1 Second Edition, WEEE, RoHS, GB 4943, Directive 2004/108/EC, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2006/95/EC, VCCI Class A, KN22 Class A, AS/NZS CISPR22:2004 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, CAN/CSA C22.2 No. 60950-1 Second Edition, EN 300 386, KN 61000-4
Software / System Requirements
Software Included Cisco NX-OS
Dimensions & Weight
Width Not specified
Depth Not specified
Height Not specified
Weight 14.99 lbs
Compatibility Information
Designed For P/N: N9K-C9504, N9K-C9504-B3-G, N9K-C9504-B3-G-P1, N9K-C9504G-PRE-D1, N9K-C9508, N9K-C9508-B3-G, N9K-C9508-B3-G-P1
