Cisco WAP571 600 Mbit/s White Power over Ethernet (PoE)


802.11ac, 1.9Gbps, 2.4 GHz, 5.0 GHz, 2x LAN Gigabit Ethernet, Wi-Fi

AED1,899.00

In today’s dynamic business environment, employees are becoming more mobile and collaborative than ever. To stay productive, they need dependable, business-class access to network applications throughout the office. CiscoĀ® WAP571 Wireless-AC/N Premium Dual Radio Access Points provide a simple, cost-effective way to extend highly secure, high-performance mobile networking to your employees and guests, so they can stay connected anywhere in the office, regardless of what mobile devices they use. This flexible solution lets you connect dozens of employees, and can scale to accommodate additional users and changing business needs. The WAP571 Wireless-AC/N Premium Dual Radio Access Point uses concurrent dual-band radio for improved coverage and user capacity. The 3×3 multiple-input multiple-output (MIMO) technology with three spatial streams allows the access point to run at maximum performance in both the 5.0-GHz and 2.4-GHz frequency. Gigabit Ethernet LAN interfaces with Power over Ethernet (PoE) facilitates flexible installation and reduces cabling and wiring costs. Intelligent quality-of-service (QoS) features let you prioritize bandwidth-sensitive traffic for voice over IP (VoIP) and video applications. To provide highly secure guest access to visitors and other users, WAP571 Wireless-AC/N Premium Dual Radio Access Points support a captive portal with multiple authentication options and the ability to configure rights, roles, and bandwidth. A customized guest login page lets you present a welcome message and access details, and reinforces your brand with company logos. WAP571 Wireless-AC/N Premium Dual Radio Access Points are easy to set up and use, with intuitive wizard-based configuration to get you up and running in minutes. An attractive design with flexible mounting options allows the access points to smoothly blend into any small-business environment. To enhance reliability and safeguard sensitive business information, WAP571 Wireless-AC/N Premium Dual Radio Access Points support both Wi-Fi Protected Access (WPA) Personal and Enterprise, encoding all your wireless transmissions with powerful encryption. In addition, 802.1X RADIUS authentication helps keep unauthorized users out. Designed to scale smoothly as your organization grows, the access points feature controller-less Single Point Setup, which simplifies the deployment of multiple access points without additional hardware. With a Wireless-AC/N Premium Dual Radio Access Point, you can extend business-class wireless networking to employees and guests anywhere in the office, with the flexibility to meet new business needs for years to come. Figure 1 shows a typical wireless access point configuration. Figures 2 and 3 show the product’s front and back panels, respectively.

SKU: WAP571-E-K9 Categories: , Tag:
Feature Description
2.4 GHz Y
5 GHz Y
Maximum data transfer rate 600 Mbit/s
Ethernet LAN data rates 10,100,1000 Mbit/s
Throughput data rate 1900 Mbit/s
Bandwidth 5 GHz
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Number of users 200 user(s)
Automatic channel selection Y
Spread spectrum method DSSS
Modulation 16-QAM, 64-QAM, 256-QAM, BPSK, OFDM, QPSK
Wi-Fi Multimedia (WMM)/(WME) Y
Number of WLAN connections (max) 21
VLAN support Y
Wireless isolation Y
Quality of Service (QoS) support Y
Receiver sensitivity See detailed specs
Security algorithms HTTPS, SNMP, SSID, WDS, WPA, WPA2
Number of SSID supported 16
Auto Wireless Distribution System (WDS) Y
DHCP client Y
Supported network protocols NTP, HTTP/HTTPS, IPv6
Management protocols SNMP v3, Bonjour
Web-based management Y
Syslog Y
Firmware upgradeable Y
Ethernet LAN (RJ-45) ports 2
WAN connection Ethernet (RJ-45)
Power over Ethernet (PoE) Y
Power consumption (max) 18 W
Placement Ceiling, Table, Wall
Product colour White
Cable lock slot Y
Cable lock slot type Kensington
On/off switch Y
Reset button Y
LED indicators Y
Certification UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC 15.247, 15.407, RSS-210, EN 300.328, EN 301.893, AS/NZS 4268.2003, FCC 15.107 + 15.109, ICES-003, EN 301.489-1 + -17
Internal N
Antenna features Integrated antenna
Antennas quantity 6
Antenna gain level (max) 1.99 dBi
Flash memory 128 MB
Internal memory 256 MB
Operating system installed Linux
Operating relative humidity (H-H) 10 – 85%
Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -20 – 70 °C
Storage relative humidity (H-H) 5 – 90%
Harmonized System (HS) code 85176990
Width 230 mm
Depth 230 mm
Height 40 mm
Weight 778 g
Cables included LAN (RJ-45)
Mounting kit Y
Quick start guide Y
