Citrix ADC MPX 5901 – Enterprise Edition – load balancing device
Tech overview
Citrix ADC MPX 5901 – Enterprise Edition – load balancing device – 10 GigE – 1U – Citrix Enterprise License Program (ELA) (Level 4) – rack-mountable
AED114,699.00
The Citrix NetScaler MPX 59xx appliance is a 1U appliance. This platform has a single 8-core processor and 16 gigabytes (GB) of memory.
| Specifications | |
|---|---|
| General | |
| Device Type | Load balancing device |
| Height (Rack Units) | 1U |
| Built-in Devices | Status LCD |
| Depth | 24 in |
| Weight | 24.91 lbs |
| Processor / Memory / Storage | |
| RAM | 16 GB |
| Hard Drive | SSD 240 GB x 1 |
| Networking | |
| Form Factor | Rack-mountable |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Network / Transport Protocol | TCP/IP, UDP/IP, ICMP/IP, FTP, DNS, RTSP |
| Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, BGP, VRRP, static IP routing, ECMP |
| Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Performance | Layer 7 throughput: 1 Gbps ¦ Request rate (layer 7): 400000 requests per second ¦ SSL throughput: 4000 transactions per second ¦ SSL throughput: 1 Gbps ¦ Compression throughput: 1 Gbps |
| Capacity | Concurrent SSL VPN users: 5000 |
| Status Indicators | Power |
| Features | NAT support, layer 7 switching, LDAP support, OCSP support, VLAN support, DoS attack prevention, packet filtering, manageable, IPv6 support, High Availability, Virtual Route Redundancy Protocol (VRRP) support, server health monitoring, Access Control List (ACL) support, Remote Desktop Protocol (RDP) support, RADIUS support, SSH support, layer 4 load balancing, DNS proxy, Equal-Cost Multipath (ECMP), IPv4 support, Global Server Load Balancing (GSLB), Link Aggregation Control Protocol (LACP), NetFlow, DNS authoritative, Management Information Base (MIB), IPFIX, Single Sign-On (SSO) support, “Always On” architecture, Management Information Base (MIB) II, Role-Based Access Control (RBAC), Power-on self-test (POST), Caller ID, Authentication, Authorization and Accounting (AAA), SPDY support, Carrier Grade NAT (CGN/CGNAT) |
| Encryption Algorithm | SSL, 2048-bit SSL, ECDHE |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+, LDAP, Active Directory, NTLM |
| Compliant Standards | IEEE 802.1Q, IEEE 802.3ad (LACP) |
| Expansion / Connectivity | |
| Interfaces | 2 x 10Gb Ethernet – SFP+ ¦ 6 x 1000Base-T – RJ-45 ¦ 1 x management (Lights-Out) – RJ-45 ¦ 1 x console – DB-9 ¦ 1 x 1000Base-T (management) – RJ-45 ¦ 2 x USB – Type A |
| Miscellaneous | |
| Compliant Standards | EIA-310-D, CSA, VCCI, NOM, CCC, FCC, RoHS, KCC, WEEE, REACH, CITC, RCM, BIS |
| Pricing Type | Citrix Enterprise License Program (ELA) (Level 4) |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Voltage Required | AC 120/230 V |
| Power Consumption Operational | 336 Watt |
| Power Provided | 450 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 – 95% (non-condensing) |
