Citrix ADC MPX 5905 – Platinum Edition – load balancing device – cloud-managed
Tech overview
Citrix ADC MPX 5905 – Platinum Edition – load balancing device – 10 GigE – 1U – cloud-managed – Citrix Enterprise License Program (ELA) (Level 6) – rack-mountable
AED134,099.00
The Citrix NetScaler MPX 59xx appliance is a 1U appliance. This platform has a single 8-core processor and 16 gigabytes (GB) of memory.
| Specifications | |
|---|---|
| General | |
| Device Type | Load balancing device |
| Height (Rack Units) | 1U |
| Built-in Devices | Status LCD |
| Depth | 24 in |
| Weight | 24.91 lbs |
| Processor / Memory / Storage | |
| RAM | 16 GB |
| Hard Drive | SSD 240 GB x 1 |
| Networking | |
| Form Factor | Rack-mountable |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Network / Transport Protocol | TCP/IP, UDP/IP, ICMP/IP, FTP, DNS, RTSP |
| Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, BGP, VRRP, static IP routing, ECMP |
| Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Cloud-Managed | Yes |
| Performance | |
| Layer 7 throughput | 5 Gbps |
| Request rate (layer 7) | 700000 requests per second |
| SSL throughput | 6000 transactions per second |
| SSL throughput | 5 Gbps |
| Compression throughput | 1.5 Gbps |
| Capacity | |
| Concurrent SSL VPN users | 5000 |
| Status Indicators | Power |
| Features | |
| NAT support, layer 7 switching, LDAP support, OCSP support, VLAN support, DoS attack prevention, manageable, IPv6 support, High Availability, VRRP support, server health monitoring, ACL support, RDP support, RADIUS support, SSH support, layer 4 load balancing, DNS proxy, ECMP, IPv4 support, GSLB, LACP, NetFlow, DNS authoritative, MIB, IPFIX, SSO support, “Always On” architecture, MIB II, RBAC, POST, Caller ID, AAA, SPDY support, CGNAT | |
| Encryption Algorithm | SSL, 2048-bit SSL, ECDHE |
| Authentication Method | SSH, RADIUS, TACACS+, LDAP, Active Directory, NTLM |
| Compliant Standards | IEEE 802.1Q, IEEE 802.3ad (LACP), EIA-310-D, CSA, VCCI, NOM, CCC, FCC, RoHS, KCC, WEEE, REACH, CITC, RCM, BIS |
| Expansion / Connectivity | |
| Interfaces | 2 x 10Gb Ethernet – SFP+ ¦ 6 x 1000Base-T – RJ-45 ¦ 1 x management (Lights-Out) – RJ-45 ¦ 1 x console – DB-9 ¦ 1 x 1000Base-T (management) – RJ-45 ¦ 2 x USB – Type A |
| Miscellaneous | |
| Pricing Type | Citrix Enterprise License Program (ELA) (Level 6) |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Voltage Required | AC 120/230 V |
| Power Consumption Operational | 336 Watt |
| Power Provided | 450 Watt |
| Software / System Requirements | |
| Software Included | Comtrade Management Pack for Citrix NetScaler |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 – 95% (non-condensing) |
