Routers
Netscaler Citrix ADC MPX 8905 – Standard Edition – load balancing device
- load balancing device
- 10 GigE
- front to back airflow
- 1U
- Citrix Education License Program
AED99,999.00
NetScaler is the advanced web and application delivery controller that maximizes the performance and availability of all applications and data, and also provide secure remote access to any application from any device type.
| General Information | |
|---|---|
| Category | Load balancer |
| Description | Citrix ADC MPX 8905 – Platinum Edition – load balancing device – 10 GigE – front to back airflow – 1U – Citrix Education License Program – rack-mountable |
| Manufacturer | Citrix Systems |
| UNSPSC | 43222622 |
| Main Specifications | |
| Dimensions & Weight / Depth | 61 cm |
| Dimensions & Weight / Height | 4.45 cm |
| Dimensions & Weight / Weight | 11.3 kg |
| Dimensions & Weight / Width | 48.3 cm |
| Header / Brand | Citrix |
| Networking / Connectivity Technology | Wired |
| Networking / Data Link Protocol |
|
| Networking / Form Factor | Rack-mountable |
| Networking / Type | Load balancing device |
| Packaged Quantity | 1 |
| Environmental Parameters | |
| Humidity Range Operating | 5 – 95% (non-condensing) |
| Max Operating Temperature | 45 °C |
| Min Operating Temperature | 0 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Built-in Devices | Status LCD, keypad |
| Depth | 61 cm |
| Device Type | Load balancing device |
| Height | 4.45 cm |
| Height (Rack Units) | 1U |
| Weight | 11.3 kg |
| Width | 48.3 cm |
| Miscellaneous | |
| Compliant Standards | EIA-310-D, CSA, UL, VCCI, C-Tick, DOC, RoHS, WEEE, FCC Part 15 A, DIN 41494, IEC 60297-3-100, TUV C |
| Pricing Type | Citrix Education License Program |
| Networking | |
| Airflow Direction | Front to back airflow |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+, LDAP, Active Directory, NTLM |
| Capacity |
|
| Compliant Standards | IEEE 802.1Q, IEEE 802.3ad (LACP) |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Encryption Algorithm | Triple DES, RC4, SSL |
| Features | Firewall protection, NAT support, layer 7 switching, LDAP support, OCSP support, VLAN support, DoS attack prevention, content filtering, packet filtering, port mirroring, manageable, IPv6 support, High Availability, Virtual Route Redundancy Protocol (VRRP) support, Access Control List (ACL) support, Remote Desktop Protocol (RDP) support, RADIUS support, SSH support, layer 4 load balancing, SSL acceleration, DNS proxy, Equal-Cost Multipath (ECMP), IPv4 support, Global Server Load Balancing (GSLB), Link Aggregation Control Protocol (LACP), NetFlow, DNS authoritative, Management Information Base (MIB), IPFIX |
| Form Factor | Rack-mountable |
| Network / Transport Protocol | TCP/IP, UDP/IP, ICMP/IP, FTP, DNS |
| Performance |
|
| Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, BGP, VRRP, static IP routing, ECMP |
| Switching Protocol | Ethernet |
| Power | |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Consumption Operational | 336 Watt |
| Power Device | Internal power supply |
| Power Provided | 300 Watt |
| Power Redundancy | Optional |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Processor / Memory / Storage | |
| Hard Drive | SSD 240 GB x 1 |
| RAM | 32 GB |
| Specifications | |
|---|---|
| General | |
| Device Type | Load balancing device |
| Height (Rack Units) | 1U |
| Built-in Devices | Status LCD, keypad |
| Width | 19 in |
| Depth | 24 in |
| Height | 1.8 in |
| Weight | 24.91 lbs |
| Processor / Memory / Storage | |
| RAM | 32 GB |
| Hard Drive | SSD 240 GB x 1 |
| Networking | |
| Form Factor | Rack-mountable |
| Airflow Direction | Front to back airflow |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Switching Protocol | Ethernet |
| Network / Transport Protocol | TCP/IP, UDP/IP, ICMP/IP, FTP, DNS |
| Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, BGP, VRRP, static IP routing, ECMP |
| Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Performance | |
| Throughput | 5 Gbps |
| SSL throughput | 5 Gbps |
| Compression throughput | 2.5 Gbps |
| Capacity | |
| Concurrent SSL VPN users | 10000 |
| HTTP requests per second | 990000 |
| SSL transactions per second (2048 certificate) | 8000 |
| ECDHE transactions per second | 4000 |
| Features | |
| Firewall protection, NAT support, layer 7 switching, LDAP support, OCSP support, VLAN support, DoS attack prevention, content filtering, packet filtering, port mirroring, manageable, IPv6 support, High Availability, Virtual Route Redundancy Protocol (VRRP) support, Access Control List (ACL) support, Remote Desktop Protocol (RDP) support, RADIUS support, SSH support, layer 4 load balancing, SSL acceleration, DNS proxy, Equal-Cost Multipath (ECMP), IPv4 support, Global Server Load Balancing (GSLB), Link Aggregation Control Protocol (LACP), NetFlow, DNS authoritative, Management Information Base (MIB), IPFIX | |
| Encryption Algorithm | Triple DES, RC4, SSL |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+, LDAP, Active Directory, NTLM |
| Compliant Standards | IEEE 802.1Q, IEEE 802.3ad (LACP) |
| Expansion / Connectivity | |
| Interfaces | 6 x 1000Base-T – RJ-45 4 x 10GBase-X – SFP+ 1 x 1000Base-T (management) – RJ-45 1 x management (Lights-Out) – RJ-45 1 x RS-232 – DB-9 2 x USB – Type A |
| Miscellaneous | |
| Compliant Standards | EIA-310-D, CSA, UL, VCCI, C-Tick, DOC, RoHS, WEEE, FCC Part 15 A, DIN 41494, IEC 60297-3-100, TUV C |
| Pricing Type | Citrix Education License Program |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 336 Watt |
| Power Provided | 300 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 – 95% (non-condensing) |
