Citrix SD-WAN 1100-200 – Premium Edition – load balancing device

Add to Wishlist

Tech overview

Citrix SD-WAN 1100-200 – Premium Edition – load balancing device – GigE – 1U – Citrix Enterprise License Program (ELA) (Level 4) – rack-mountable

AED29,199.00

Add to Wishlist

Citrix SD-WAN increases the performance and reliability of traditional enterprise applications, SaaS applications and virtual desktops over any network while simplifying the branch network.

Enterprises can use Citrix SD-WAN to software define their WAN, rendering it more scalable, cost-effective and ready to connect to the cloud, while ensuring excellent application performance. At the same time, Citrix SD-WAN can help you to effectively and economically simplify the branch network with integrated routing, firewall, and WAN optimization capabilities.

SKU: 3026603-E4 Category: Tag:
Specifications Details
General
Device Type Load balancing device
Height (Rack Units) 1U
Width 19 in
Depth 9.8 in
Height 1.7 in
Weight 8.6 lbs
Processor / Memory / Storage
RAM 32 GB
Hard Drive SSD 123 GB x 1
Hard Drive (2nd) SSD 25 GB x 1
Networking
Form Factor Rack-mountable
Connectivity Technology Wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol TCP/IP, IPSec, PPPoE, DHCP, DNS
Routing Protocol OSPF, BGP, static IP routing, GRE
Remote Management Protocol SNMP 3, CLI
Performance Throughput: 200 Mbps
Capacity Maximum virtual paths (dynamic): 32 Ā¦ Maximum virtual paths (fixed): 64
Status Indicators Port status, port transmission speed, power, PoE, link/activity, bypass
Features Firewall protection, routing, NAT support, MPLS support, VLAN support, Syslog support, Quality of Service (QoS), DHCP server, DHCP relay, NetFlow, DHCP client, GRE tunneling, Open Shortest Path First (OSPF), IP Security (IPSec) support
Encryption Algorithm 128-bit AES, 256-bit AES
Authentication Method RADIUS, PAP, CHAP, TACACS+
Compliant Standards IEEE 802.1Q
Expansion / Connectivity
Interfaces 1 x 1000Base-TX (management) – RJ-45 Ā¦ 1 x console – RJ-45 Ā¦ 2 x USB 3.0 – Type A Ā¦ 4 x 1000Base-T – RJ-45
Miscellaneous
Included Accessories Rubber feet
Compliant Standards EIA-310-D, UL, VCCI, NOM, FCC Part 15 B, CCC, MOC, RoHS, KCC, WEEE, DIN 41494, EAC, CITC, RCM, IEC 60297
Pricing Type Citrix Enterprise License Program (ELA) (Level 4)
Power
Power Device Internal power supply
Installed Qty 1
Voltage Required AC 120/230 V
Power Provided 200 Watt
Dimensions & Weight (Shipping)
Shipping Width 18.5 in
Shipping Depth 26 in
Shipping Height 6.5 in
Shipping Weight 14.55 lbs
Environmental Parameters
Min Operating Temperature 50 Ā°F
Max Operating Temperature 95 Ā°F
Humidity Range Operating 8 – 90% (non-condensing)
